5. Press the shutter release button all the way to release the shutter when both
LED in-focus indicators light up to indicate subject in-focus condition.
For further information on view'ftnder information, etc., refer to the F3AF
camera body's instruction manual.
Focus detection range when lens is a1 infinity («>)
Lens In use Focus defecHon range
300mm Infinity {■») to 35m (114.8 ft)
200mm Infinity (oo) to 16m (52.5 ft)
135mm Infinity (oo) to 7.2m (23,6 ft)
105mm Infinity («>) to 4.4m (14.4 ft)
85mm Infinity (<») to 2 9m (9.5ft)
58mm Infinity (») to 1.4m (4.6 ft)
55mm Infinity (oo) to 1,3m (4.3 ft)
50mm Infinity (“) to 1.2m (3.9 ft)
35mm Infinity {») to 0.61m (2 ft)
28mm Infinity (») to 0,42m (1.4 ft)
24mm Infinity (<») to 0.33m (1.1 ft)
Notes:
1. All focus detection operating ranges are approximate.
2. If your subject is outside the focus detection range, the LED focus-impossible
warning indicator (x) or far-focus indicator (◄) will light up inside the DX-1
AF Finder. In this case, turn the prime lens’s focusing ring to less than
infinity (<»); the distance set now becomes the maximum shooting distance
of the prime lens’ focus detection range, so its focus detection range from
maximum to minimum is correspondingly decreased. You can then focus on
the subject even if it falls outside the range tabled.
For example, when using
50mm f/1.8 as the prime
lens, its focus detection
range changes as in the
following diagram.
prime lens's focusing ring
