Briggs & Stratton 724 PRO Twin
Ref. No. Part No. Description
220 BS-690412 Washer (Governor Gear)
221 BS-841026 Cup-Governor
222 BS-796226 Bracket-Control
227 BS-796223 Lever-Governor Control
231 BS-690718 Screw (Choke Valve)
239 BS-792028 Switch-Oil Pressure
240 BS-695666 Filter-Fuel
250 BS-690957 Retainer-Breather
252 BS-794389 Collector-Oil
265 BS-691024 Clamp-Casing
267 BS-695134 Screw (Casing Clamp)
276% BS-695410 Washer-Sealing
278 BS-792651 Washer (Governor Control Lever)
287 BS-697551 Screw (Dipstick Tube)
304 BS-797407 Housing-Blower
305 BS-691005 Screw (Blower Housing)
305A BS-790690
Screw (Blower Housing to Intake
Elbow)
306 BS-796541 Shield-Cylinder (Cylinder #2)
306A BS-796852 Shield-Cylinder (Cylinder #1)
307 BS-697551 Screw (Cylinder Shield)
309 BS-497595 Motor-Starter
310 BS-690323 Screw (Starter Motor)
332 BS-691059 Nut (Flywheel)
333 BS-691060 Armature-Magneto
334 BS-691061 Screw (Magneto Armature)
337 BS-491055S Plug-Spark
358 BS-694012 Gasket Set-Engine
385 BS-797409 Screw (Fuel Pump)
387 BS-808656 Pump-Fuel
404 BS-690442 Washer (Governor Crank)
415 BS-794903 Plug (Oil Pressure Switch Hole)
418 BS-795912 Plate-Carburetor
431 BS-792297 El bow-Intake
445 BS-792105 Filter-Air Cleaner Cartridge
447 BS-691003 Screw (Air Guide Cover)
467 BS-790697 Knob-Air Cleaner
474 BS-696457 Alternator
501 BS-794360 Regulator
Ref. No. Part No. Description
503 BS-691532 Strap-Starter
505 BS-691029 Nut (Governor Control Lever)
510 BS-696541 Drive-Starter
513 BS-692024 Clutch-Drive
523 BS-691036 Dipstick
524+ BS-691032 Seal-Dipstick Tube
525 BS-691037 Tube-Dipstick
526 BS-691129 Screw (Regulator)
544
Armature-Starter (Service with Starter
Motor 497595, Reference 309)
552 BS-796638 Bushing-Governor Crank
552A BS-690553 Bushing-Governor Crank
562 BS-690311 Screw (Governor Control Lever)
573 BS-790444 Plate-Back
579 BS-691029 Nut (Starter Cable)
601 BS-691038 Clamp-Hose (Black)
615 BS-698290 Retainer-Governor Shaft
616 BS-691045 Crank-Governor
617 BS-697891 Seal-0 Ring (Intake Manifold) (Red)
633% BS-699813 Seal-Choke/Throttle Shaft
634 BS-698779 Spring/Seal Assembly
635 BS-66538S Boot-Spark Plug
654 BS-690958 Nut (Carburetor)
668+ BS-691215 Spacer (Rotating Screen)
668A BS-691500 Spacer (Rotating Screen)
672 BS-690234 Gasket-Carburetor Plate
691 + BS-790574 Seal-Governor Shaft
695 BS-693149 Screw (Ring Gear)
697 BS-690372 Screw (Drive Cap)
703 BS-691010 Clip
718 BS-690959 Pin-Locating
726 BS-499612 Gear-Ring
729 BS-797454 Clip-Wire
741 BS-690980 Gear-Timing
742 BS-690328 Retainer-E Ring (Governor Crank)
750 BS-796208 Screw (Oil Pump Cover)
+ — Included in Engine Gasket Set, Key. No. 358
& — Included in Valve Gasket Set, Key No. 1095
% — Included in Carburetor Overhaul Kit, Key No. 121
