PARTS LIS
I
Hood and Dash Model No. 247.28980
J
Ref.
No.
Part No. Description
1 631-04353P Dash Lever
2 710-04484 Taptite Screw, Lock Washer, 5/16-18:.750
3 710-0599 Taptite Screw, Lock Washer, 1/4-20:0.500
4 710-0895 Hi-Lo Screw, Lock Washer, 1/4-15:0.750
5 710-0896 Screw, Lock Washer, 1/4-14:0.625
6 710-1017 Screw, 1/4-14:0.625
7 710-1611B Taptite Screw, 5/16-18:0.750
8 710-3217 Machine Screw, #8-32:0.375
9 712-0142 Hex Nut, #8-32:GRA
10 714-04040 Bow-tie Cotter Pin
11 726-3046 Ratchet Clip:.250 DIA
12 731-07456 Dash
13 731-07550 Control Knob
14 732-04580 Extension Spring, .500 DIA X 2.733 LG
15 735-0271A Bumper
16 735-04076 Accessory Net
17 747-05280 Control Rod Latch
18 747-1196 Lever Rod
19 783-04285F-0637 RH Dash Support Plate
20 783-04323F-0637 LH Dash Support Plate
21 625-04124 Keys (Set of 2)
22 683-04618-0691 Hood Assembly
23 710-04187 Hi-lo Screw, Lock Washer, 1/4-15:0.50
24 710-05108 Screw, Lock Washer, 1/4 DIA:.750
Ref.
No.
Part No. Description
25 931-07457 Grill
26 731-07458 RH Lens
27 731-07459 LH Lens
28 931-07461 Hood Scoop
29 731-07467 Lower Grill
30 731-07469 LH Hood Scoop
31 731-07470 RH Hood Scoop
32 738-04091A Shoulder Screw, .43X.29:TT:5/16-18
33 710-0642 Taptite Screw, 1/4-20:0.750
34 747-05049 RH Tank Support Rod
35 747-05050 LH Tank Support Rod
36 751-0603A Fuel Cap
37 951-10573 Fuel Tank, 2.75 Gallons
38 946-04556 Throttle/Choke Control
39 735-04170 Fuel Tank Gasket
40 731-07495 P-Style Plen
41 925-0963 Miniature Lamp, 12V
42 925-1649 Lamp Socket
43 725-04992 Switch Key Module
44 689-00157 Guard Assembly
45 712-04065 Flangelock Nut, 3/8-16
46 738-0143 Shoulder Bolt, .496 x .336:3/8-16
47 925-04036C Hour Meter
48 725-04258 PTO Switch
