Craftsman 247.28980 - Manual (Page 54)

Briggs & Stratton 724 PRO Twin
Ref. No. Part No. Description
1 BS-793564 Cylinder Assembly
2 BS-499585 Kit-Bushing/Seal (Magneto Side)
3+ BS-391086S Seal-Oil (Magneto Side)
4 BS-796307 Sump-Engine
5 BS-796231 Head-Cylinder (Cylinder #1)
5A BS-796232 Head-Cylinder (Cylinder #2)
7+& BS-693997 Gasket-Cylinder Head
8 BS-792185 Breather Assembly
9+ BS-690937 Gasket-Breather
10 BS-697551 Screw (Breather Assembly)
11 BS-792184 Tube-Breather
12+ BS-697227 Gasket-Crankcase
13 BS-793988 Screw (Cylinder Head)
15 BS-690946 Plug-Oil Drain
16 BS-796540 Crankshaft
20+ BS-795387 Seal-Oil (PTO Side)
22 BS-694966 Screw (Crankcase Cover/Sump)
23 BS-691053 Flywheel
24 BS-222698S Key-Flywheel
25 BS-792023 Piston Assembly (Standard)
25 BS-792072 Piston Assembly (.020” Oversize)
26 BS-793561 Ring Set (Standard)
26 BS-792073 Ring Set (.020” Oversize)
27 BS-690975 Lock-Piston Pin
28 BS-696581 Pin-Piston
29 BS-796209 Rod-Connecting
32 BS-690976 Screw (Connecting Rod)
33 BS-697576 Valve-Exhaust
34 BS-792200 Valve-Intake
35 BS-694865 Spring-Valve (Intake)
36 BS-694865 Spring-Valve (Exhaust)
42 BS-499586 Keeper-Valve
45 BS-690977 Tappet-Valve
46 BS-797242 Gear-Cam
48 BS-797093 Short Block
50 BS-695241 Manifold-Intake
51 + BS-795123 Gasket-Intake
51A BS-690950 Gasket-Intake
51B BS-690949 Gasket-Intake
Ref. No. Part No. Description
53 BS-690951 Stud (Carburetor)
54 BS-699816 Screw (Intake Manifold)
73 BS-494439 Screen-Rotating
74 BS-698425 Screw (Rotating Screen)
75 BS-691056 Washer (Flywheel)
95 BS-690718 Screw (Throttle Valve)
98 BS-699721 Kit-Idle Speed
104% BS-694918 Pin-Float Hinge
105 BS-698537 Valve-Float Needle
108 BS-699723 Valve-Choke
117 BS-842630 Jet-Main (Standard)
118 BS-797477 Jet-Main (High Altitude)
121 BS-792455 Kit-Carburetor Overhaul
125 BS-796997 Carburetor
130 BS-690993 Valve-Throttle
131 BS-499805 Kit-Throttle Shaft
133 BS-699724 Float-Carburetor
135 BS-699729 Tube-Fuel Transfer
137% BS-690994 Gasket-Float Bowl
141 BS-796228 Kit-Choke Shaft
142 BS-699726 Nozzle-Carburetor
146 BS-690979 Key-Timing
150 BS-690995 Gasket-Nozzle
163+% BS-691001 Gasket-Air Cleaner
165 BS-693148 Nut (Ring Gear)
186 BS-795985 Connector-Hose
187 BS-791766 Line-Fuel (Cut to Required Length)
188 BS-697551 Screw (Control Bracket)
192 BS-690083 Adjuster-Rocker Arm
197 BS-697820 Screw (Back Plate)
209 BS-796658 Spring-Governor (Yellow/Brown)
211 BS-796225 Spring-Governed Idle (Orange)
212 BS-695238 Link-Throttle
216 BS-796229 Link-Choke
217 BS-695409 Spring-Choke Return
219 BS-793338 Gear-Governor
+ — Included in Engine Gasket Set, Key. No. 358
& — Included in Valve Gasket Set, Key No. 1095
% — Included in Carburetor Overhaul Kit, Key No. 121
54
