PARTS LIS
I
J
PTO and Battery — Model No. 247.28980
Ref.
No.
Part No.
Description
1
683-04469A-0691
Frame
2
710-04484
Taptite Screw, indented Washer, 5/16-18:.750
3
710-0599
Taptite Screw, indented Washer, 1/4-20:0.500
4
710-3005
Hex Head Screw, 3/8-16:1.25
5
712-04065
Flangeiock Nut, 3/8-16
6
738-04058
Shouider Spacer, .38 X 1.0 X .70
7
747-04121A
Battery Holder Rod
8
783-0349-0637
Battery Tray
9
783-06089-0637
Seat Frame Bracket
10
710-04379A
Hex Head Screw, 7/16-20:3.50
11
917-04163A
Electric PTO Clutch
12
725-0157
Cable Tie, 3/16 x.05x7.4
13
936-0171
Lock Washer, 7/16
14
736-0277
Flat Washer, 1.031 x 1.620 x.095
15
712-0271
Sems Nut, 1/4-20
16
756-0978B
Electric PTO Engine Pulley
17
710-04666
Hex Head Flange, 1/4-20:.75
18
747-05171
Belt Guard
19
725-05088
Battery
20
725-04439
Solenoid, 12 V
21
712-04064
Flangeiock Nut, 1/4-20
22
725-04363
Interlock Switch
23
738-04237A
Shoulder Screw, #10-32:.500
45
