TRACTOR--MODEL NUMBER917.275031
SCHEMATIC
posmoN CIRCUIT “MAKE”
OFF M*G*A1 NONE
ON+UGHTS B +A1 L+A2
ON B + A1 NONE
START B*S + A1 NONE
RELAY
POSITION CIRCUIT
OFF C+Q.B + H
ON C + F.B^'E.A + D
WIRING INSULATED CUPS
NOTE: IF WIRING INSULATED
CUPS WERE REMOVED FOR
SERVICING OF UNIT. THEY
SHOULD BE REPLACED TO
PROPERLY SECURE YOUR
WIRING.
REMOVABLE
CONNECTIONS
NON-REMOVABLE
CONNECTIONS
G F C
I I )
!^l
I I
D A
33
