LOOSE PARTS LIST

1. Saw Assembly.......................................................1

Check all loose parts from the box with the list below. Use the instructions on the following pages to assemble.

All fasteners are shown actual size.

SAW ASSEMBLY SHOWN AS PACKED

2. Elevating Handwheel

A. Handwheel...................................................... 1

B. Screw (10-24 x 5/8 in. Soc. Hd.).................. . 1

C. Star Washer....................................................1

3. Blade Wrench

Fig. 5

..... 2

4. Hex Key

A. 3/16 in. Hex Key.

B. 1/4 in. Hex Key...
