CRAFTSMAN 21" - 5H.P. SNOW THROWER 536.885210

WHEEL ASSEMBLY

REF.

NO.

PART NO.

PART NAME

650
651
660

661
662

313678

583409
760713
583409
577598

Axle, Shaft
Washer, Rat .391x1.00x.l2i
Tire & Rim 7x1.50
Washer,Flat .391x1,00x.125

Ring, Retaining

314097C

662

REF.

NO.

PART NO.

PART NAME

REF.

NO.

♦

PART NO.

PART NAME

740

313449

Cable, Upper Control 11.95

753

782585

Nut, 1 /4-20 Reghexctrik

741

313441

Brkt, Cable Adjust

760

333919-853

Upper Handle

742

313448

Cable, Lower Control 16.00

761

333954-853

Control Bail

743

308146

Boot, Clutch Spring

762

337584

Bolt, 5/16-18x2.00 CUH

744

313471

Spring, Extension

763

311936

Formed Washer

750

333909-853

Lower Handle

764

57171

Knob, T 3.00

751
752

313674
71067

Screw 1/4-20x1.25

Washer, Rat .281x.63x.065

765

71037

Nut, 5/16-18 Reghex

334312A
