REPAIR PARTS
SEARS TRIMMER MODEL 358.791031
116 .
J 4
^7-o
lk 18 20 21
Sh,
WARNING
All repairs, adjustments and
maintenance not described in
the Operator’s Manual must be
performed by qualified service
personnel.
=44 I 42
/1
■^3 -
\ 35
X
^P\
f.;A \i\ \
58 J X
Ref. Part No. Description Ref. Part No. Description Ref. Part No. Description
1. 530015880 Screw 22. 530039229 Ignition Module 45. 530032125 Inner Bearing
2. 53005SDS2 Bolt-Muffier 23. 530016357 Screw 46. 530012579 Assy-Crankshaft
3. 530057863 Assy-Mufffer/Shield 24. 545054801 Assy-Wire 47. 530071750 0-Ring-C’case (kit)
(Incl. 2) 25. 545054901 Spring-Starter 48. 530057954 Assy-Plug (tncl.47)
4. 530015953 Screw-Cylinder 26, 545015803 Assy.-Fan Hsg 49. 530016386 Screw
5. Champion Spark Plug (RCJ 6Y) 27. 530016386 Screw 50. 530057539 Shroud-Rear
e. 530012541 Cylinder 28, 530054834 Handle-Starter 51. 530016445 Retainer-Tank
7. 530071750 Seal-Cylinder (kit 29. 545050409 Kit-Rope 52. 530057974 Assy-Fuel Tank (incl.
8. 530071785 Kit-Piston/Rod Assy 30. 530055122 Assy-Clutch filter, lines & fuel cap)
(Incf. 9 & 12) 31, 530094189 Washer-Clutch 53. 530057973 Assy-Fuel Cap
9. 530069945 Assy-Conn. Rod 32. 530015772 Screw 54. 530069247 Kit-Fuel Line (Small)
10. 530055120 Piston Ring 33, 530015814 Screw 55. 530069216 Kit-Fuel Line (Large)
11. 530015162 Retainer-Piston Pin 34. 545050407 Kit-Pulley-Starter 56. 530095646 Assy-Fuel Pickup
12. 530071833 Kit-Piston{1nc!.10,11 35, 545080601 Baifle-Fan 57, 530071750 Kit-Engine Gasket
13. 530071750 Seal-Cy!/Carb.(kit) 36. 530015880 Screw-Baffle (Incl. 7,13,16,47)
14. 530057547 Adapter-Carb. 37. 530059758 Spacer 58. 530150247 Assy-Clutch drum
15. 530016441 Screw 38, 530016463 Washer 59. 530059757 Assy-C!utch Cover
10. 530071750 Gasket-Carb. (kit) 39. 530039243 Assy-Flywheel (Incl, 61,62)
17. 530071811 Kit-Carb.iClU-W19 40, 530071951 Assy-C’case/C’shaf 60 530015772
(Noxe: Heparr kiis are noi avallarne (Ind. 41,42,46) 61. 530016381 Screw
for this carburetor') 41, 530012582 Assy-Crankcase 62, 530016382 Nut-#12-24
18. 530059246 Air Box (Incl. 43,44,45)
19. 530016429 Screw 42, 530015941 Retain. Ring-C’shaf Not S lown
20. 530036575 Foam-Air Filter 43, 530055728 Outer Bearing 530058709 Bulb-Purge
21. 530057545 Cover-Air Box 44. 530019264 Seal-Cease
23
