ASSEMBLY
CARTON CONTENTS
Check carton contents against the fol
lowing list.
Model 358.791031
• Powerhead
• Trimmer attachment
• Shield
• Wing nut (screwed onto shield)
• Container of oil
Examine parts for damage. Do not
use damaged parts.
NOTE:
If you need assistance or find
parts missing or damaged, call
1-800-235-5878.
It is normal for the fuel filter to rattle in
the empty fuel tank.
Finding fuel or oil residue on muffler is
normal due to carburetor adjustments
and testing done by the manufacturer.
ASSEMBLY
^WARNING; Always stop unit
and disconnect spark plug before per
forming any assembly procedures.
^WARNING: If received as
sembled, repeat all steps to ensure
your unit is properly assembled and all
fasteners are secure.
iNSTALLiNG TRIMMER ATTACH
MENT
CAUTION:
When installing trimmer
attachment, place the unit on a flat
surface for stability.
1. Loosen the coupler by turning the
knob counterclockwise.
Coupler
Shipping
protector
LOOSEN
TIGHTEN
Knob
Remove shipping protector from
coupler.
Remove the shaft cap from the
trimmer attachment (if present).
Position locking/release button of
attachment into guide recess of
coupler.
Push the attachment into the cou
pler until the locking/release button
snaps into the primary hole.
Before using the unit, tighten the
knob securely by turning clock
wise.
Coupler
Primary Hole
Guide Recess
11 ’'Ü8*.......
R°etease Attachment
Button
aWARNING:
Make sure the lock
ing/release button is locked in the pri
mary hole and the knob is securely
tightened before operating the unit. All
attachments are designed to be used in
the primary hole unless otherwise
stated in the applicable attachment op
erator’s manual. Using the wrong hole
couid lead to serious injury or damage
to the unit.
For optional attachments, see the
AS
SEMBLY
section of the applicable at
tachment operator's manual.
ATTACHING SHIELD
^WARNING: The shield must be
properly installed. The shield provides
partial protection from the risk of thrown
objects to the operator and others and
is equipped with a line limiter blade
which cuts excess line to the proper
length. The line limiter blade (on under
side of shieid) is sharp and can cut you.
For proper orientation of shield, see
KNOW YOUR TRIMMER
illustration in
OP
ERATION
section.
1. Remove wing nut from shield.
2. Insert bracket into slot as shown.
3. Pivot shield until bolt passes
through hole in bracket.
4. Securely tighten wing nut onto
bolt.
