TRACTOR - - MODEL NUMBER 917^70711

SCHEMATIC

IGNmON SWITCH

posmoN

CIRCUir

*MAKE*

OFF

G + M - fL -MONE

RUNAJ6KT

B * L

A + V

BUM

B * L

NONE

START

B * L * S

- NONE

NOTE

YOUR TRACTOR IS

EQUIPPED WITH A SPECIAL

ALTERNATOR SYSTEM.

THE LIGHTS ARE NOT

CONNECTED TO THE

BATTERY, BUT HAVE THEIR

0\«N ELECTRICAL SOURCE.
BECAUSE OF THIS, THE

BRIGHTNESS OF THE UGHTS

WILL CHANGE WITH ENGINE

SPEED. AT IDLE THE UGHTS

WILL DIM. AS THE ENGINE IS

SPEEDED UP. THE LIGHTS ..

WILL BECOME THEIR BRIGHTEST.

NON-REMOVABLE

CONNECTIONS

REMOVABLE

CONNECTIONS

WIRING INSULATED CUPS

NOTE: IF WIRING INSULATED CUPS WERE REMOVED FOR

SERVICING OF UNIT, THEY SHOUL&BE REPLACED TO

PROPERLY SECURE YOUR WIRINa
