Craftsman 917.270711 - Manual (Page 37)

TRACTOR - - MODEL NUMBER 917.270711
GROUND DRIVE
KEY PART KEY PART
NO. NO. DESCRIPTION NO. NO. DESCRIPTION
1 Transaxte (See Breakdown) 56 STD523712 Bolt Fin Hex 3/8-16x1-1/4
. Peerless 206-508B 57 130801 V-BeK, Ground Drive
2 146682 Spring, Return, Brake 58 127274X Keeper, BeK, R.H.
3 123666X Pulley, Transaxle 59 140312 Ke^>er, BelL Center Span
4 12000028 Ring, Retainer 61 17490612 Screw, Thd., RolL 3/8-16 x 3/4
5 121520X Strap, Torque 62 8883R Cover, Pedal
6 17490512 Screw, Thd, RoB. 5/16-18 x 3/4 63 140186 Pulley, Engine
8 ' 154792 Rod Shifter Fender STLT 64 71170764 BoR, Hex Head, Rn.
10 STD561210 - Pin, Cotter 7/16-20x4 Grade 5
11 105701X Washer, Shift Plate 65 STD551143 Washer
13 74550412 Bolt 1/4-28 UNF W/Patch Gr. 8 66 154778 Keeper, Belt, Engine, Fool-
14 STD551125 Washer Proof
■ 18 STD523710 Bolt nn Hex 3/8-16 UNC x 1. 70 134683 Guide, Mower Drive Belt, R.H.
Gr5 72 19132012 Washer 13/32 x 1-1/4 x 12 Ga.
19 STD541437 Nut 74 137057 Spacer, Axle
21 106933X Knob 75 121749X Washer 25/32 x 1-1/4 x 16 Ga.
22 130804 Rod, Brake 76 STD581075 E-Ring
24 STD541237 Nut 77 123583X Key,Square 2.0x.1845/.1865
25 106888X Spring, Brake Rod 78 121748X Washer 25/32x1-5/8x16
26 STD551037 Washer
Gauge
27 STD561210 Pin 79 2228M Key Woodruff #9 3/16x3/4
28 145204 Rod, Parking Brake 80 145090 Arm, Shift
29 124236X Cap, Parking Brake, Red 81 161082 Shaft Assembly
30 130807 Bracket, Transaxle 82 123782X Spring, Torsion
31 127275X Keeper, Belt, LH. 83 19171216 Washer 17/32 x 3/4 x 16 Ga.
32 STD523107 Bolt
84 145643 Tie Rod
34 155071 Shaft/Assembly, Foot Pedal 85 150360 NuL Nylock
35 120183X Bearing, Nylon 86 157480 Bushing
36 STD551062 Washer 87 19212016 Washer
37 STD571810 Roll Pin 88 12000008 E-Ring
38 123674X Pulley, Idler, Flat 89 158391 Console, Shift, STLT
39 STD523727 Bolt
90 124346X Nut, Self-Thding, Wsh Hd 1/4
40 4470J Spacer, Split .395 x .59 96 4497H Retainer Spring 1’
41 154777 Keeper, Belt, Idler Fool-Proof 112 19091210 Washer 9122. x 3/4 x 10 Gauge
42 19131312 Washer 13/32 x 13/16 x 12 Ga. 113 121520X Strap Torque LhLt
47 127783 Pulley, Idler, V-Groove, Plastic 116 72110610 Bolt Rdhd Sqneck 3/8-16 x 1.25
48 154407 Bellcrank Clutch Gmd Drv SB 145 74490540 Boft, Hex FIghd 5/16-18 Gr. 5
49 123205X Retainer, Belt 148 159103 Spacer
50 STD523715 Bolt 149 122052X Spacer Retainer PM Mower
’"'51 STD541437 Nut CroVvn Lock 3/8-16 UNC 150 150935 ■'Bushing Nylon Collered
52 STD541431 Nut Crown Lock 5/16-18 UNC 151 19133210 Washer 13/32 x2x 10 Ga.
53 10571OX Link, Clutch NOTE:: All component dimensions give in U.S.
55 105709X Spring, Clutch Return inches 1 inch = 25.4 mm
