CONTENTS OF HARDWARE PACKAGE IN CART CARTON
Ref. Qty.
Description
Ref. Qty.
Description
A
3
Bolt, Hex 3/8"
X
3"
Z
11
Hex Nut, 1/4"
В
2
Bolt, Hex 1/4"
X
1-3/4"
BB
14
Hex Nut, 5/16"
D
2
Bolt, Hex 3/8"
X
1-1/4"
EE
5
Nut, Hex Lock 3/8"
J
9
Bolt, Hex 1/4"
X
5/8“
GG
2
Pin, Cotter 1/8" x 1-1/2"
M
14
Bolt, Truss Head 5/16“ x 3/4"
HH
1
Hair Cotter Pin. 1/8"
0
11
Lockwasher, 1/4"
II
2
Hub Cap
P
14
Lockwasher, 5/16"
JJ
2
Spacer Tube
Q
5
Lockwasher, 3/8"
KK
2
Door Support
R
2
Flat Washer. 1/4"
NN
1
Hitch Pin
X
4
Flat Washer, 1"
CONTENTS OF (2) VAC HARDWARE PACKAGES IN VAC CARTON
Ref.
Qty.
DescriptiorT
Ref.
Qty.
Description
C
1
Hex Bolt, 1/2"
X
1-1/4"
Y
2
Hex Nut, #10-32
E
2
Hex Bolt, 1/4"
X
1-1/4"
Z
46
Hex Nut, 1/4"
G
4
Hex Bolt, 1/4" x1"
AA
2
Hex Lock Nut, 1/4“
H
6
Hex Bolt, 5/16“
X
3/4"
DD
9
Nylock Nut, 5/16"
J
30
Hex Bolt. 1/4“
X
5/8“
EE
2
Hex Lock Nut, 3/8"
L
4
Hex Bolt, 5/16"
X
3/4" Thread Forming
FF
1
Hex Lock Nut, 1/2"
N
2
Truss Bolt Head, #10-32 x 5/8"
LL
1
Hitch Plate
0
40
Lockwasher, 1/4“
MM
3
Knob
P
4
Lockwasher, 5/16"
00
1
Tarp Strap, 25"
R
26
Flat Washer, 1/4“
PP
2
Tarp Strap (Less Hooks)
S
6
Nylon Washer
2
"S" Hooks
T
3
Flat Washer, 5/16"
RR
2
Eye Bolt
u
4
Flat Washer, 3/8“
SS
1
Door Latch (RH)
V
1
Flat Washer, 7/16“
TT
1
Door Latch (LH)
w
4
Flat Washer, 11/32“ x 1-1/2"
UU
3
Hinge
CONTENTS OF DECK ADAPTER HARDWARE PACKAGE IN VAC CARTON
Not all parts in this list will be used for any one tractor.
Ref. Qty.
Description
F
2
Hex Bolt, 5/16" x1"
1
3
Hex Bolt, 1/4" X 3/4"
К
2
Carriage Bolt, 5/16" X 3/4"
R
3
Flat Washer, 1/4“
S
3
Nylon Washer
T
12
Flat Washer, 5/16"
AA
3
Hex Lock Nut, 1/4"
CC
3
Hex Lock Nut, 5/16"
W
1
Mounting Strap
WW
1
Angle Bracket
XX
1
Mounting Bracket |
