REPAIR PARTS FOR MODEL 486.24516 CHIPPER VAC SYSTEM
REF.
NO.
PART
NO.
QTY.
DESCRIPTION
REF.
NO.
PART
NO.
QTY.
DESCRIPTION
1
24080
1
Engine Base
37
43178
44
Nut, Hex 1/4-20
2
24078
2
Brace, Housing
38
43177
38
Lockwasher, Spring 1/4"
3
63226
1
Hose Hanger Bracket Ass'y.
39
24582
3
Hinge, Poly Top
(Ref. item #16 on page 22.)
40
1543-69
9
Washer, Nylon 21/64"
4
43182
14
Bolt. Hex 5/16-18x3/4"
41
43351
1
Bolt, Hex 1/2-13x1-1/4"
5
43063
2
Bolt, Hex 5/16-18x1"
42
43262
1
Nut, Hex Lock 1/2-13
6
43085
4
Bolt. Hex 5/16-18x1-1/2"
43
43352
1
Washer, Flat 7/16"
7
43086
16
Lockwasher, 5/16" Spring Type
44
43081
15
Washer, 5/16" STD
8
43064
15
Nut, Hex Lock 5/16-18
45
43830
1
Adapter, Deck
9
63375
1
Assembly, Hose Adapter (Nozzle)
46
23560
1
Bracket, Deck Adapter
(Includes items W a n d 11))
47
43080
2
Bolt, Carr. 5/16" X 3/4"
10
781-0635
1
Bracket, Switcti (Actuator)
48
23825
1
Mounting Strap
11
728-3001
3
Rivet. Pop 5/32"
49
23826
1
Angle Bracket
12
43012
8
Bolt, Hex 1/4-20 x 3/4"
50
23827
1
Mounting Bracket
13
43013
10
Nut, Hex Lock 1/4-20 Thd.
51
47630
4
Screw, Self Tap 5/16-18 x 3/4"
14
7520155481 1
Engine, 8 HP Tecumseh
52
712-0421
3
Knob (See also Item #8, Page 28)
15
222261
1
Reflector, Muffler
53
1
Impeller Housing Assembly
16
63227
1
Hose Hanger Rod Ass'y.
(See page 28)
17
46420
1
Elbow
54
62468
1
Deck Adapter Kit (Includes parts in
18
43792
1
Hose (6" X 84")
box shown on page 26)
19
43793
2
Hose Clamp 6"
55
44419
2
Eyebolt, 1/4"
20
24608
2
Side Panel Cart Extension
56
47640
1
Handle, Dump
21
24609
1
Front Panel Cart Extension
57
43364 ■
2
Bolt, Truss Hd. #10-32 X 5/8"
22
24610
2
Side Bracket ("Z")
58
43662
2
Nut, Hex #10-32(SEMS)
23
63918
1
Hard Top Assembly
59
23476
2
Rod, Tie
(Includes 24,25,26,27)
60
47642
1
Rod, Prop (RH)
24
43882
8
Rivet, 3/16"
61
47641
1
Rod, Prop (LH)
25
43910
8
Washer, Flat 3/16"
62
43070
4
Washer. Flat 3/8"
26
23842
4
Boot Mounting Strap
63
43082
4.
Nut, Hex Lock 3/8-16
27
46480
1
Hard top Boot
64
24612
1
Latch, Door (RH)
28
44790
1
Poly Rear Door
65
24613
1
Latch. Door (LH)
29
43790
1
Strap, Tarp 25"
66
47810
6
Nut, Nylock, 5/16-18
30
44849
2
"S"Hook, #32
67
63376
1
Assy., Chute, Chipper (Upper)
31
44850
2
Strap, Tarp (Less Hooks)
68
735-0249
1
Flap, Chute
32
23540
1
Hitch Plate
69
781-0633
1
Strap, Flap
33
43866
30
Bolt, Hex 1/4-20 x 5/8"
70
47810
3
Nut, Hex Lock 5/16"
34
43661
2
Bolt, Hex 1/4-20x1"
71
24098
1
Bracket, Chute Reinforcement
35
43088
59
Washer, 1/4" STD
72
731-1617
1
Tamper, Plug
36
1509-90
2
Bolt, Hex 1/4-20x1-1/4"
73
681-0068
1
Chute Assembly
47813
r
Owner's Manual
