Craftsman 921.153101 - Manual (Page 4)

Important Satoty Insinielions & Quit/ellneB
Risk to Breathing Avoid using ihs air compressor In conHnod areas. Always have adequate space
(12 inches) on all sktas oF the air oompreasor. Also keep children, pats, and others out
of the area of operation. This air compressor does net provide breathable air for anyone
or any auMliary breathing device. Spraying material will always need to be in another
area away from the air compressor to not allow Intake air to damage the air compressor
filter,
Risk of
Electrical Shock
'i*
. V
Never utilize tha air compressor in the ram or wet conditions. Any electrical issues or
repairs should be performed by autiiorized peiaonnel such as an electrician and should
comply with all national and local electrical codes. The air compressor should also have
the proper three prong groundmg plug, correct voltage, and adequate fuse protection.
RisIlOf
Explosion oi nn
■- ^ " r_ ■»
fNayer opeóte tte compresor.near combustible materials, garollne'cr soKjerit ya^j^;'
If spraying flammable materials, locate me air compressor at least 20 feet array from
the spray area. Never operate the air compressor indoors or In a confined area
Rick of Bursting Always drain the air compressor tank daily or after each use. If the tank develops a leak,
then replace the air compressor. Never use the air compressor after a leak has been
found or try to make any modifications to the tank. Never modify the air compressor's
factory settings which control the tank pressure or any other fundón.
Specifications
Pump .........................................Oil-lube direct drive-
Motor Induction......................... 1.S HP max developed,
1 HP tunning
Bore ................. ..........................1.65"
Stroke............ ........................1,26"
Voltage Single Phase....... ........ >20 VAC
Glossary
CFM: Cubic feet per minute.
SCFM: Standard cubic Feet per minute; a unit of maasure
for air dellve^.
PSIG: Pounds per square Inch gauge; a unit of measure
for pressure.
ASME: American Society of Mechanical Engineers.
California Code: Unit rnsy comply with Canfomla Code
462 (I) (2)/ (M) (2).
Cut'In Pressure; The air compressor will automatically
start to refill the tank when the pressure drops
below the prescribed minimum
Duty Cycle
This IS a 50% duty cycle air compressor. Do not run the air
could damage toe air compressor.
Minimum Circuit Requirement__ 15 Amps
Air Tank Capacity ..................... ^ Gatigns
Cul4n Pressure...........................95 PSI
Cut-out Pressure................... . .125 PSI
SCFMOSOPSI.............................2.4
Cui-Out Pressure; The point at which the motor stops
when the tank has reached maximum air
pressure.
Code Certification: Products that bear one or more of -
the following marks: UL, CUL,'ETL, CSA, have ■
been evaluated by OSHA-oertifled Independent
safety laboratories and meet the applicable
Underwriters Laboratories Standards for Safety
compressor more than 30 minutes of one hour. Doing sc
