ACCESSORIES AND ATTACHMENTS CARTON CONTENTS
RECOMMENDED ACCESSORIES
A
WARNING
Visit your Sears Hardware Department or see the Craftsman
Power and Hand Tools Catalog to purchase recommended
accessories for this power tool.
A
WARNING
To avoid the risk of personal injury:
• Do not use adjustable (wobble) type dadoes or carbide
tipped dado blades; maximum dado width is 1/2”.
• Do not use a dado with a diameter larger than 6”.
• Do not use molding head set with this saw.
• Do not modify this power tool or use accessories not
recommended by Sears.
TOOLS NEEDED FOR ASSEMBLY
TOOLS NEEDED
Medium screwdriver
I _ _ __ j
t*2 Phillips screwdriver
AdpstabI® wrench
W i
Straicnt edge Combinatioh square
UNPACKING AND CHECKING CONTENTS
Separate all parts from packing materials. Check each part
with the illustration on the next page and the “Table of Loose
Parts” to make certain all items are accounted for, before
discarding any packing material.
A
WARNING
If any part is missing or damaged, do not attempt to
assemble the table saw, plug in the power cord, or turn the
switch ON until the missing or damaged part is obtained and
is installed correctly.
TABLE OF LOOSE PARTS
ITEM
A.
B.
c.
D.
E.
F.
G.
H.
I.
J.
K.
L.
M.
N.
O.
X.
Y.
STAND
P.
Q.
R.
S.
T.
u.
V.
w.
DESCRIPTION QUANTITY
1 Table saw assembly
Table extension 2
Rear table extension 1
Rear table extension tube 2
Looation seat 5
Blade guard and splitter 1
Guard Mounting bolt, flat washer,
toothed washer, oval washer,
spring wasjer 1 each
Rip fence 1
Hand wheels 2
Dome nuts 2
Dado table insert 1
Miter gauge 1
Hex keys 1
Blade wrenches 2
Blade 1
Dust chute 1
Dust bag 1
Top short leg bracket 2
Top long leg bracket 2
Bottom short bracket 2
Bottom long bracket 2
Legs 4
Roller wheel assemblies &
mounting hardware 1
Stand mounting hardware 1
Fence storage hardware &
Parallel washers 1
NOTE: To make assembly easier, keep contents of box together.
Apply a coat of automobile wax to the table. Wipe all parts
thoroughly with a clean dry cloth. This will reduce friction when
pushing the workiece.
