PARTS LIST
10” TABLE SAW PARTS LIST MODEL NO. 137.248830
A
WARNING
When servicing use only CRAFTSMAN replacement parts. Use of any other parts may create a HAZARD or cause product
damage.
A
WARNING
Any attempt to repair or replace electrical parts on this Table Saw may create a HAZARD unless repair is done by a qualified
service technician. Repair service is available at your nearest Sears Service Center.
Schematic A
Always order by Model Number and I.D. number.
I.D. No. Description Size Qtv I.D. No. Description Size Qty
2178 EXTENSION WING (RIGHT) 1 OKCX CR.RE. PAN HD PLAIN WASHER
TAPPING SCREW M5*0.8-10 4
2179 EXTENSION WING (LEFT) 1 OKSW STRAIN RELIEF 1
09JK WRENCH HEX. #06 1 OKWZ LEAD WIRE ASS'Y 1
0B31 TABLE 1 10GN UPERTUBE 1
0B3H INSERT 1 10GP UPERTUBE 1
0B3K INSERT 1 10GQ RIP FENCE ASS'Y
1
0B3R WRENCH 1 10H4 UPERTUBE 1
0B84 WASHER D=(p18 1 10H5 UPERTUBE 1
0BC2 LOCATION SEAT #06 5 20KA SCALE 1
OBCW UPERTUBE 2 20KC SCALE 1
OBCX EXTENSION WING 1 20KD SCALE 1
0BD2 WARNING LABEL 1 20WQ HEX. HD. BOLT M6*1.0-50 1
0BD3 WARNING LABEL 1 20Z7 BLADE GUARD ASS'Y 1
0J3U WRENCH HEX. 1 211Q SCALE 1
0J5L FLAT WASHER 0 5*10-0.3 1 0 211R SCALE 1
0J6V FLAT WASHER 3/16*3/8-0.022 6 22KU WARNING LABEL 1
0J76 FLAT WASHER 1/4*3/4-1/16 1
0B8A WARNING STICK LABEL
1
0J95 SPRING WASHER q) 6 1 OTOO SLIDING BASE ASS'Y 1
OJAA WASHER 0 8 1 0T03 SLIDING BASE ASS’Y 1
OJAF EXTERNAL TOOTH LOCK WASHER 1 OSZY
SLIDING BASE ASS'Y
1
0K9U HEX. HD. TAPPING SCREW M5*16-25 8 OSZZ SLIDING BASE ASS'Y 1
OKAP CR.RE. PAN HD. TAPPING SCREW M5*0.8-10 1 26J7 TRADE-MARK LABEL 1
OKCH CR.RE. PAN HEAD TAPPING SWASHER SCREW M5*0.8-12 2 28FE
CAUTION LABEL
1
