10” TABLE SAW

Part list for STAND

MODEL NO. 137.248830

I.D. No.

Description

Size

Qty

0A4T

BASE

#06

2

OEAA

BRACKET

4

OEAN

UPPER SUPPORT

1

OEAP

UPPER SUPPORT

1

OEAY

UPPER SUPPORT

2

0EB8

BOTTOM SUPPORT BRACKET

2

OEBG

BOTTOM SUPPORT BRACKET

2

0J4F

FLAT WASHER

to

8X16-2.5

4

OJPP

HEX. HD. BOLT

M8X1.25-30

4

0K7K

CR. RE. ROUND WASHER HD. SCREW

M6X1.0-12

2

0Z1G

CAP HD. SQ.NECK BOLT

M8X1.25-12

16

OKRQ

SERRATED TOOTHED HEXAGON FLANGE NUT

M6X1.0T=6

2

OKRR

SERRATED TOOTHED HEXAGON FLANGE NUT

M8X1.25 ■ T=7.5

20

243R

LEFT FRONT WHEEL ASS’Y

1

243S

LEFT REAR WHEEL ASS’Y

1

243T

RIGHT FRONT WHEEL ASS’Y

1

243U

RIGHT REAR WHEEL ASS’Y

1

26
