Craftsman 247.388250 - Manual (Page 23)

CRAFTSMAN ENGINE NO. 143.994002 FOR
CRAFTSMAN 4.0 H.P. LAWN MOWER MODEL 247.388250
Key No. Part No. Description Qty. Key No. Part No. Description Qty.
1 37280 Cylinder (Incl. 2,20 & 150) 130 6021A Screw, 5/16-18 X 1-1/2" 8
2 26727 Dowel Pin 2 135 35395 Resistor Spark Plug (RJ19LM) 1
6 33734 Breather Element 1 150 31672 Valve Spring 2
7 36557 Breather Ass'y. (Incl. 6 & 12A) 1 151 31673 Valve Spring Cap 2
12 36775 Breather Tube 1 151A 40017 Intake Valve Seal 1
12A 36558 Breather Cover & Tube (Incl. 12B) 1 169 36783 Valve Cover Gasket 1
12B 36694 Breather Tube Elbow 1 172 36784 Valve Cover 1
14 28277 Washer 1 174 30200 Screw, 10-24x9/16" 2
15 30589 Governor Rod (Incl. 14) 1 178 29752 Nut& Lock Washer, 1/4-28 2
16 34839A Governor Lever 1 182 6201 Screw, 1/4-28 X 7/8" 2
17 31335 Governor Lever Clamp 1 184 26756 Carburetor - Intake Pipe Gasket 1
18 651018 Screw, Torx T-15, 8-32x19/64" 1 185 36785 Intake Pipe 1
19 36281 Extension Spring 1 186 32653 Governor Link 1
20 32600 Oil Seal 1 189 650839 Screw, 1 /4-20 X 3/8" 2
30 36797 Crankshaft 1 191 36559A S.E. Brake Bracket (Incl. 195) 1
40 35544A Piston, Pin & Ring Set (Std.) 1 195 610973 Terminal 1
40 35545A Piston, Pin S Ring Set (.010" OS) 1 207 34336 Throttle Link 1
40 35546 Piston, Pin & Ring Set (.020" OS) 1 216 33086 R.P.M. Adjusting Lever 1
41 35541 Piston & Pin Ass'y. (Std.) (Incl. 43) 1 223 650451 Screw, 1/4-20 X 1" 2
41 35542 Piston & Pin Ass'y. (.010" OS) 1 224 36786 Intake Pipe Gasket 1
(Incl. 43) • 238 650932 Screw, 10-32x49/64" 2
41 35543 Piston & Pin Ass'y. (.020" OS) 1 239 34338 Air Cleaner Gasket 1
(Inci. 43) 241 35797 Air Cleaner Collar 1
42 35547A Ring Set (Std.) 1
245 35066 Air Cleaner Filler 1
42 35548A Ring Set (.010" OS) 1 250 35065 Air Cleaner Cover 1
42 35549 Ring Set (.020 OS) 1 260 36980 Blower Housing 1
43 20381 Piston Pin Retaining Ring 2 261 30200 Screw, 10-24x9/16" 2
45 36777 Connecting Rod Ass'y. (Incl. 46) 1
262 650831 Screw, 1/4-20x1/2" 2
46 3261OA Connecting Rod Bolt 2 275 36790A Muffler 1
48 27241 Valve Lifter 2 277 650988 Screw, 1/4-20x2-5/16" 2
50 37032 Camshaft (NCR) 1
285 35000A Starter Cup 1
52 29914 Oil Pump Ass’y. 1 287 650926 Screw, 8-32x21/64" 2
69 35261 Mounting Flange Gasket 1 290 29774 Fuel Line 1
70 34311 E Mounting Flange (Incl. 72 thru 1 292 26460 Fuel Line Clamp 2
83,306)
298 28763 Screw, 10-32 X 35/64" 3
72 36083 Oil Drain Plug 1
300 36916 Fuel Tank (Incl. 292 & 301) 1
75 27897 Oil Seal 1
301 36246 Fuel Cap 1
80 30574A Governor Shaft 1
305 35647 Oil Fill Tube 1
81 30590A Washer 1
306 36996 "0"-Ring 1
82 30591 Governor Gear Ass'y. (Incl. 81) 1
307 35499 "0"-Ring 1
83 30588A Governor Spool 1
309 650562 Screw, 10-32x1/2" 1
86 650488 Screw, 1/4-20 X 1-1/4" 6
310 35648 Dipstick 1
89 611004 Flywheel Key 1
313 34080 Spacer 1
90 611112 Flywheel 1
370A 36261 Lubrication Decal 2
92 650815 Belleville Washer 1 370C 37199 Primer Decal 1
93 650816 Flywheel Nut 1
370K 36695 Starter Decal 1
100 34443B Solid State Ignition 1
380 640173 Carburetor (Incl. 184) 1
101 610118 Spark Plug Cover 1
390 590737 Rewind Starter* 1
103 651007 Screw, Torx T-15, 10-24 x 15/16" 2
400 37029A Gasket Set 1
110 37047 Ground Wire 1
416 36085 Spark Arrestor Kit (Optional) 1
119 37028 Cylinder Head Gasket 1
417 650821 Screw, 10-32 X 1/2" (Optional) 1
120 36825 Cylinder Head
900 0 Replacement Engine NONE, order
125 37288 Exhaust Valve (Std.) (Incl. 151) 1 from 71 -9990
126 37289 Intake Valve (Std.) (Incl. 151) 1 900 0 Replacement Short Block 750836 1
' This engine could have been built with 590694 starter
