PARTS LIST - MODEL 183.172530
(A
WARNING
When servicing use only CRAFTSMAN replacement parts. Use of any other parts may create a HAZARD or cause
damage to your Cutting Tool.
Any attempt to repair or replace electrical parts on this Cutting Tool may create a hazard unless repair is
performed by a qualified technician. Repair seit^ce is available by contacting your nearest Sears Service Center.
Always order by PART NUMBER, not by key number.
Main Unit
Key#
Part#
Part Name
Qty
Key#
Part#
Part Name
Qty
1
01AR-000032-00
Bearing Sleeve
1
44
03AT-000033-00
Terminal blocR
1
2
01AR-000035-00
Switch presser
1
48
03AT-000040-00
Terminal (femaie)
2
3
01AT-000014-AO
Bushing tube
2
49
03AT-000046-00
Carbon brush
2
5
01AT-000031-00
Bushing tube
2
50
03AW-000131-00
Power cord
1
10
02AE-000060-00
Front bearing
1
53
03AY-000020-00
Wire
1
11
02AE-000061-00
Rear bearing
1
55
03AY-000073-00
Wire
2
_12
02AK-000022-00
Rivet
4
56
03AY-000074-00
Wire
2
13
02AH-000088-00
Brush spring
2
59
04AP-000068-00
Fibra
1
14
02AH-000089-00
Spindle spring
1
62
2203-MA0003-00
1/4" collet
1
15
02AH-000112-00
Hanger
1
62
2203-MA0004-00
1/8" collet
1
17
02AS-000199-AO
Case screw
8
63
2203-MA0007-00
Lock plate
1
18
02AS-000201-AO
Screw
3
67
2207-MA0003-00
Spindle lock
1
22
02AW-000055-00
Retaining ring
1
70
2213-MA0002-00
Conductor
2
23
03AA-000279-00
Transformer
1
71
2213-MA0005-00
Chuck cap
1
24
03AC-000011-FO
Capacity
1
72
2213-MA0006-00
Spanner
1
25
03AC-000043-00
Capacity
1
*
2213-SAM001-00
Brush assembly
2
28
03AD-000009-AO
Diode
4
73
2213-MA0011-00
Metal conductor
2
29
03AD-000040-00
Diac
1
74
2213-MA0012-00
Brush case
2
30
03AD-000074-00
LED
2
76
2213-MAO014-00
Wire cover
1
31
03AD-0000754)0
Triac
1
77
2213-MA0015-00
Stop plate
1
34
03AM-000104-00
Stator
1
79
2203-PAOd08-00
Spanner belt
1
35
03AM-000105-00
Rotor
1
81
2213-PAOCQ2-00
Bottom cabinet
1
36
03AP-000073-00
PCB
1
82
2213-PA0023-00
Top cabinet
1
37
03AP-000076-00
PCB
1
83
2213-PA0024-00
Switch cover .
1
38
03AR-000013-AO
Resistor
1
84
2213-PA0025-00
Lock button
1
39
03AR-000015-DO
Resistor
1
85
2213-PA0026-00
Cover
1
40
03AR-000109-AO
Resistor
3
87
2213-PA0028-00
2P-Switch
1
41
03AS-000135-00
Micro switch
1
91
9866-PA0004-00
Press ptate
1
42
03AS-000140-00
Switch
1
92
9920-PA0011-00
Cord Sleeve
1
