PARTS
J
CRAFTSMAN 2,150 PSi Pressure Washer 580.752010
Main Unit — Exploded View and Parts List
iOO —
C
-J" '
///il
/ / / / / /
V . .
i/ 'f, ■T"i[ v‘ Item Part# Description Items Not Illustrated 1 196519GS BASE Part# Description 2 192525GS KIT, Pump/Engine Mounting 195927GS MANUAL, Owners Hardware AB3061BGS OIL BOTTLE 3 196006GS HOSE 195851ZZGS NOZZLE, QC Black 4 193482GS GUN 195983AEGS NOZZLE, QC, Red 5 192199GS ASSY, Extension 195983AFGS NOZZLE. QC, Yellow 6 196278GS KIT, Spray Tips 195983AHGS NOZZLE, QC, White 7 194298GS RELIEF, Thermal 87815GS GOGGLES 8 23139GS KEY 192703GS DECAL, Clean Carry 9 194216GS ASSY, Pump (see page 21) 196712GS KIT, Decal, Srv 900 NSP ENGINE (10D902-0133-D2) 192754GS DECAL, Warning Optional Accessories Not illustrated 3Ct 7175187GS Garden Hose Quick Conn« 190249GS 25' Replacement Hose 7175116GS O Ring Repair Kit 100513GS 25'Extension Hose 7174403GS Pump Saver 20
7175197GS Accessory Quick Connect
7175199GS Rotating Brush Kit
7174300GS House Wash Concentrate (makes 4 gallons)
7174301GS Deck Wash Concentrate (makes 2 gallons)
7174302GS Vehicle/Boat Wash Concentrate (makes 4 gallons)
7174303GS Degreaser Concentrate (makes 4 gallons)
7174307GS Mold/Mildew Concentrate (makes 2 gallons)
