BRIGGS AND STRATTON 5 H.P. ENGINE MODEL NO. 133402-0011-01
Repair Parts
REF.
NO.
PART
NO.
DESCRIPTION
54
94705
Screw-Hex.Head
284
94620
Screw-Hex. Hd.
300
494562
Muffler-Exhaust
613
94729
Screw-Sem
832
494903
Guard-Muffler
864
494904
Flange-Muffler
883
*272309
Gasket-Exhaust
REF.
NO.
PART
NO.
DESCRIPTION
182
224709
Bracket-Fuel Tank
184
93559
Screw-Hex. Hd.
185
94010
Nut-Hex.
187
393815
Line-Fuel (11" Long, Cut to Suit)
187A
495218
Pipe-Fuel (Molded)
188
94357
Screw-Hex. Head
429
281190
Cover-Spark Plug
601
93053
Clamp-Fuel Pipe (Green)
Note: 93807 Clamp-Fuel Pipe
(Black)
957
493988
Cap-Fuel Tank
958
494539
Valve Ass’y.-Fuel Shut-Off
972
495345
Tank Ass’y.'Fuel
‘Included in Gasket Set—Part No. 495661.
^188
Assemblies include all parts shown in frames.
25
