ENGINE PARTS
CRAFTSMAN 2400 PSI HIGH PRESSUIRE WASHER 919.679240
BRIGGS ENGINE MODEL «120602-01350-E2
258 ©
REF. PART
NO. NO. DESCRIPTION
REF. PART
NO. NO. DESCRIPTION
p^p PART
NO.' NO. DESCRIPTION
4 499619 Sump-Engine
258 94220 Screw-Hex.
43 493737 Govemor/Oil Slinger
12 *272198 Gasket-Crankcase
------------Note----------
46 499749 Gear-Cam
15 94880 Plug-Oil Drain
94612 Screw-Hex.
20 *399781 Seal-Oil
One Used in Hole
Nearest Breather.
* Included in Gasket Set-Part No. 692702.
A Included in Valve Overhaul Kit-Part No. 692705.
Included in Carburetor Kit-Part No. 692703
Included in Carburetor Gasket Set-Part No. 692704.
Assemblies include all parts shown in frames.
21
