ENGINE PARTS
CRAFTSMAN 2400 PSI HIGH PRESSUIRE WASHER 919.679240
BRIGGS ENGINE MODEL «120602-01350-E2
I REF,
NO.
PART
NO.
DESCRIPTION
REF.
NO.
PART
NO. DESCRIPTION
REF
NO.
PART
NO.
DESCRIPTION
1
692670 Cylinder Assembly
45
262679 Tappet-Valve
619
94744 Screw-Hex.
2
399269 Bushing
51>*>i692668 Gasket-Intake
635
66538 Bool-Spark Plug
3
*299819 Seal-Oil
122i«*»i692799 Spacer-Carburetor
718
230192 Pin-Locating
5
692800 Head-Cylinder
155
225325 Plate-Cylinder Head
630
499756 Stud-Rocker Arm
7 *A273240 Gasket-Cylinder Head
189
263108 Ball-Rocker Arm
866 *A498592 Seal-Valve
8
495786 Breather Assembiv
238
263131 Cap-Valve
883 *A273348 Gasket-Exhaust
9
*272481
Gasket-Breather
306
225366 Shield-Cylinder
993 *A273346 Gasket-Plate
10
94955 Screw-Hex.
O U J
337
1 W %_)wi W W r 1
Pliirw5=;n;)rW
1019
693B6B Label Kit
11
499675 Tube-Breather
383
19374 Wrench-Spark Plug
1022 *A273241
Gasket-Rocker Cover
13
95049 Screw-Hex.
529
281736 Grommet
1023
499624 Cover-Rocker
33
499642 Valve-Exhaust
584
224328 Cover-Breather
1026
498597 Rod-Push
34
499641
Valve-Intake
Passage
1029
225246 Arm-Rocker
35
263149 Spring-Valve
585
*272238 Gasket-Breather
1034
281621 Guide-Push Rod
40
93312 Retainer-Valve
Passage
*: Included in Gasket Set-Part No, 692702.
A Included in Valve Overhaul Kit-Part No. 692705.
• Included in Carburetor Kit-Part No. 692703
♦ Included in Carburetor Gasket Set-Part No. 692704.
Assemblies include all parts shown in frames.
