Craftsman 917.274040 - Manual (Page 49)

TRAPTflR
HYDRO GEAR TRANSAXLE - ■
■ - MODEL NUMBER 917.274040
MODEL NUMBER 314-0510
KEY PART KEY PART
NO. NO. DESCRIPTION NO. NO. DESCRIPTION
1 170351 Main Housing, Assembly 59 170408 Rotor, Brake
2 170352 Side Housing, Assembly 60 142883 Brake Puck
3 170353 Center Section, Assembly 61 142881 Puck Plate
4 170354 Swashplate, Trunion Machined 62 142887 Brake Actuating Pin
5 169898 Block - Assembly 63 170410 Hfhcs 1/4-20x2 W/Patch,
6 170355 Sealant 10.5 Oz SpecialFlange
7 170356 Hex Flange Screw 1/4-20 X 1.25 64 142892 Bolt, 1/4-20 X 1 W/Paich
8 170357 Stud, 5/16-24 Hex Double End 65 170411 Spacer
9 170358 Shaft, Input 66 189386 Spring, Brake Arm Bias
10 170359 Ring - Retaining 67 170413 Sq. Hd. Bolt 5/16-24-Ribbed
11 170360 Spacer 68 170414 Arm, Brake
12 169870 Ring - Retaining 69 170415 Slotted Hex Nut 5/16-24
13 170361 Seal, Lip .67 X 1.58 X .276 70 170416 Cotter Pin 3/32 X 3/4
14 169869 Ball Brg 17mm Id X 40mm Od X 71 170417 Compression Spring Brake Anti-
12mm Drag
16 170362 Hex Flange Head Screw 5/16- 72 170418 Washer, Hi .5 I.D. X 1 O.D. X .032
24X0.75 73 142884 Flat - Washer 11/32 I.D, X 7/8 O.D
17 170363 Lip Seal 1 8 X 3 2 X 7 7 4 170419 Oil Seal .625 X 1.0 X .25
18 170364 Arm, Control 75 170420 Check Plug Assembly,
19 150771 Bearing, 30x52x13 Thrust .027,Washer
23 170365 Check Plug Assembly, Washer 76 170421 Stud, 5/16-24 Friction Pack
24 170366 Shaft, Motor 77 170422 Puck, .330 X 1.50 X .0975
27 170367 Gear - Pinion, 13t 78 142969 Spring, Helical Comp
28 170368 10t/48t Gear 79 142980 Spacer
29 170369 Gear, 10t Jackshaft 80 150778 Hex Lock Nut 5/16-24Unjf{Nylon
30 170370 60t Bull Gear Insert)
31 170371 Sleeve Bearing .75 X 1.575 X 81 170423 Wedge, Friction Pack
.625 82 170424 Clip, Washer .316x1.50x.1046
32 170389 Sleeve Bearing(Outboard) (Plated)
.75x1.750X.625 83 161162 Pin, Standard Headless
33 142991 Washer, 3/4 Id X 1-1/2 Od X .13 84 170425 Fitting, 5/16 Sae 5/32 Tube
Thk 85 170426 Hose, Expansion Tank
34 170390 Lip Seal Axle Seal 86 170427 Expansion Tank
35 170391 Shaft, Axle .75 X 11.39 (Key, R.H.) 87 170424 Cap - Poppet Valve
36 170392 Shaft, Axle .75 X 16.99 {Key, L.H.) 88 170429 Bolt, Self Tapping 10-32 X 1/2
37 150792 Miter Gear (Splined) 90 170430 Puck, Inner Wedge
38 150793 Miter Gear 15t (0.5 Id) 93 170431 Spring Clip - Housing Thrust
39 150809 Shaft 107 170432 Deflector
40 170393 Ring, Spiral Retaining 108 170433 Washer,Motor Shaft
41 170394 Pin, Jackshaft .71idx1.15odx.030thk
42 170395 Magnet, Ring 109 170434 Plug, Sae #6
43 170396 Spring, Bypass 111 170435 0-Ring .07 X .301 I.D.
44 150797 Hydro Mtg Screw 3/8-24 X 2.5 112 170436 Shield, Vent
Long 113 170437 Bracket, Support Expansion Tank
45 170397 Filter 116 170438 Silicon Sponge
46 170398 Base, Filter 119 170439 Fan, 7 In.
47 170999 Actuator, Bypass 120 170440 Pulley
48 170400 Rod, Bypass Actuator 121 170441 Hex Lock Nut 1/2-20 (Nylon
49 170401 Arm, Bypass Insert)
50 170202 Retaining Ring .250 External 122 170442 Washer, Belleville
51 170403 Seal, Lip .741 X .250 X .250 Tc 123 170443 Belt Keeper
52 170404 Flat Washer, 5/8 Id X 1.0 Od X 124 170444 Center Section-Filfer-Bypass
.05 Thk Assembly
53 170405 Retaining Ring 125 170445 Filter Assembly
54 170406 Bearing, Center Block 126 170446 Fan - Pulley Service Assembly
55 142977 Spring - Helical Compression 127 170447 Seal - 0-Rlng Kit
56 142978 Washer 900 166768 Transaxle Complete
57 20W-50 Oil
58 170407 Brake Yoke NOTE1: All component dimensions given in U.S. inches
49
