External Control Device Setup
26. ISM Method (Command2:p)
► To avoid having a fixed image remain on screen.
Transmission
][Set ID][ ][Data][Cr]
Data 0: Normal
1 : White wash
Acknowledgement
2: Orbiter
3: Inversion
[p][ ][Set ID][ ][OK][Data][x]
27. Low Power (Command2:q)
► To control the low power function on/off.
Transmission
][SetlD][ ][Data][Cr]
Data 0: Low power off
1: Low power on
Acknowledgement
[q][ ][Set ID][ ][OK][Data][x]
28. Orbiter Time Setting (Command2:r)
► To adjust orbiter operation time term.
Transmission
ü][r][ ][SetlD][ ][Data][Cr]
Data Min: 1 ~ Max: FE
Acknowledgement
[r][ ][Set ID][ ][OK][Data][x]
29. Orbiter Pixel Setting (Command2:s)
► To adjust pixel number In orbiter function.
Transmission
ü][s][ ][Set ID][ ][Data][Cr]
Data Min: 1 ~ Max: 9
Acknowledgement
[s][ ][Set ID][ ][OK][Data][x]
30. Picture Size Setting for Double Window
mode (Command2:t)
► To adjust main window size In Double Window mode.
Transmission
][SetlD][ ][Data][Cr]
Data Min: 0 ~ Max: 14
• Refer to ‘Real data mappIngT. See page 35.
Acknowledgement
][Set ID][ ][OK][Data][x]
31. Auto Configure (Command2:u)
► To adjust picture position and minimize image shaking
automatically. It works only In RGB (PC) mode.
Transmission
[j][u][ ][Set ID][ ][Data][Cr]
Data 1 : To set
Acknowledgement
[u][ ][SetlD][ ][OK][Data][x]
32. Tune command (Command: m a)
► Tune channel to following physical number
Transmission
[m][a][ ][Set ID][ ][DataO][ ][Data1][ ][Data2][ ][Data3][Cr]
Dafa 0
1
2
3
Air: 02 ~ 45, Cable: 01, OE ~ 7D
0
0
High Main Channel: 0, Sub Channel: 1
Low Air: 0, CATV: 1
Acknowledgement
[a][ ][Set ID][ ][OK][DataO][ ][Data1][ ][Data2][ ][Data3][x]
33. Channel Add/Del (Command: m b)
► To add and delete the channels
Transmission
[m][b][ ][SetlD][ ][Data][Cr]
Data 0: Channel Memory
1 : Channel Erase
Acknowledgement
[b][ ][Set ID][ ][OK][Data][x]
34. Key (Command: m c)
► To send IR remote key code
Transmission
[m][c][ ][Set ID][ ][Data][Cr]
Data Key code: Refer to page 40.
Acknowledgement
[c][ ][SetlD][ ][OK][Data][x]
38 Plasma TV
