External Control Device Setup
18. Bass (Command2:s)
► To adjust bass.
You can also adjust bass in the Sound menu.
Transmission
[k][s][ ][Set ID][ ][Data][Cr]
Data Min: 0 ~ Max: 64
• Refer to ‘Real data mapping 1’. See page 35.
Acknowledgement
[s][ ][SetlD][ ][OK][Data][x]
19. Balance (Command2:t)
► To adjust balance.
You can also adjust balance in the Sound menu.
Transmission
[k][t][ ][Set ID][ ][Data][Cr]
Data Min: 0 ~ Max: 64
• Refer to ‘Real data mapping 1’. See page 35.
Acknowledgement
][Set ID][ ][OK][Data][x]
20. Color Temperature (Command2:u)
► To adjust color temperature.
You can also adjust ACC in the Picture menu.
Transmission
[k][u][ ][SetlD][ ][Data][Cr]
Data 0: Cool 1: Normal
Acknowledgement
2: Warm 3: Off
[u][ ][Set ID][ ][OK][Dafa][x]
21. Red Adjustment (Command2:v)
► To adjust red in color temperature.
Transmission
[k][v][ ][Set ID][ ][Data][Cr]
Data Min: 0 ~ Max: 3C
• Refer to ‘Real data mapping 3’ as shown right.
Acknowledgement
[v][ ][SetlD][ ][OK][Data][x]
22. Green Adjustment (Command2:w)
► To adjust green in color temperature.
Transmission
[k][w][ ][Set ID][ ][Data][Cr]
Data Min: 0 ~ Max: 3C
• Refer to ‘Real data mapping 3’ as shown right.
Acknowledgement
[w][ ][Set ID][ ][OK][Data][x]
23. Blue Adjustment (Command2:$)
► To adjust blue in color temperature.
Transmission
[k][$][ ][Set ID][ ][Data][Cr]
Data Min: 0 ~ Max: 3C
• Refer to ‘Real data mapping 3’ as shown below.
Acknowledgement
[$][ ][Set ID][ ][OK][Data][x]
Real data mapping 3
-30
-29
-28
1E : 0
3A : +28
3B : -
h 29
3C : +30
24. PIP Input Select (Command2:y)
► To select input source for sub picture in PIP mode.
Transmission
[k][y][ ][SetlD][ ][Data][Cr]
Data 0
1
2
3
TV
Video 1
Video 2
Component 1
Component 2
RGB
DVI
Acknowledgement
[y][ ][SetlD][ ][OK][Data][x]
25. Abnormal State (Command2:z)
► To recognize an abnormal state.
Transmission
[k][z][ ][Set ID][ ][FF][Cr]
Data FF:Read
Acknowledgement
[z][ ][SetlD][ ][OK][Data][x]
Data 0: Normal (Power on and signal exist)
1: No signal (Power on).
2: Turn the monitor off with remote control.
3: Turn the monitor off with Sleep Time function.
4: Turn the monitor off with RS-232C function.
5: 5V down.
6: AC down.
7: Turn the monitor off with Fan Alarm function.
8: Turn the monitor off with Off Time function.
9: Turn the monitor off with Auto Off function,
a: Turn the monitor off with On Time function.
(It you do not press any button within 2 hours after
the TV turns on with the On Timer function, the TV will
automatically revert to standby mode.)
Owner’s Manual 37
