Specifications
Video Camera Recorder
System
Video recording system: Two
rotary heads. Helical scatming,
FM system
Audio recording system: Rotary
heads, FM system
Video signal: NTSC color, EIA
standards
Usable cassette: 8 mm video
format cassette (standard 8 mm)
Tape speed: Approx.
19/32 inches (1.43 cm)/second,
Approx. 5/16 inches
(0.72 cm)/second (playback only)
Recording time: SP mode 2 hours
(P6-120)
Playback time: 2
hours (P6-120), 4
hours (P6-120)
Fastforward/rewind time:
Approx. 6 min. 30 sec. (P6-120)
Image devide: CCD (Charge
Coupled Device)
Viewfinder: See the table below.
Lens: See the table below.
Color temperature: Auto
Minimum illumination: See the
table below.
Illumination range: See the table
below.
Recommended illumination:
More than 100 lx
Output connector
Video output Phono jack, 1 Vp-p,
75 Q, unbalanced, sync negative
Audio output See the table
below.
RFU DC OUT: Special minijack,
DC5V
Headphones/Earphone jack: See
the table on the next page.
LANC jack: Stereo mini-minijack
(o
23 mm)
MIC jack: See the table on the next
page.
General
Power requirements: On battery
mounting surface 6.0 V (battery
pack), 7.5 V (AC power adaptor)
Average power consumption:
See the table on the next page.
Installation: Vertically,
Horizontally
Operating temperature: 32°F to
104‘>F(0'>Cto40®Q
Storage temperature: -4°F to
+140“F(-20«Cto+60°Q
Dimensions: See the table on the
next page.
Mass: See the table on the next
page.
Microphone: See the table on the
next page.
Supplied accessories: See page 5.
Model CCD-TR42 CCD-TR70 CCD-TR72 CCD-TR80 CCD-TR82 Notes
Viewfinder B/W Color B/W Color B/W Electronic
viewfmder
Lens 12
X
10
X
12
X
Combined power
zoom lens. Filter
diameter 11/2
inches (37 mm),
TTL autofocus
system inner
focus wide macro
system
Focal distance
f = 7/32-25/8
in (5.4-64.8
mm)
7/32-21/4
in (5.4-54
mm)
7/32 - 2 5/8 in (5.4 - 64.8 mm)
—
—
9/32-31/8
in (6.5-78
mm)
at Steady Shot
19/16-
18 1/2 in (39
-468 nun)
19/16-
15 3/8 in (39
-390 mm)
19/16-181/2 in
(39 - 468 mm)
17/8-
221/4 in (47
- 564 mm)
When converted
into a 35-nun still
camera
Minimum
illuminations 2lx 5U F1.8
Illumination
range
2-100,000 lx 5-100/)001x
—
Audio output Monaural 2: stereo L and R Monaural Phono jack 7.5
dBs, (at output
impedance
47 kD)
impedance less
than 2.2 kO
See the next page for further information.
