Setting up and Tuning the Modulator
Perform the following steps after your multi-room distribution system
has been connected properly.
1 Connect the output (mini-jack) of the power supply to the modulator
unit and plug the power supply into a 110 V AC wall outlet.
The green LED Power indicator should illuminate. If it does not,
recheck all power connections.
2
Turn on the main TV. The mode of your TV (CATV or antenna)
will determine the "in-house" channels you will use.
□ If antenna, you will use UHF channels between 14 and 35
inclusively.
□ TF cable, you will use CATV channels between 54 and 86
inclusively.
Refer to your notes made of channels delivered to your home
(page 7).
3
Select your "in-house" channels and make a written note of what
they will be. Select a charmel for the second video source even if
one will not be used.
□ For CATV: use channels higher than that of your notes.
Highest Channel Set INPUT 1 Set INPUT 2
34 54 56
65 67 69
□ For antenna: select any bf the' unused channels provided that
they are at least one unused channel apart from one another and
at least one unused channel away from a channel with a picture.
Highest Channel Set INPUT 1 Set INPUT 2
15,16,17, 20,
24,25,26
16 26
14,15,19,20, 21 14 20
Installation Instructions 11
