Using Your Monitor
Preset and user modes
The Multiscan CPD-IOOVS monitor has factory preset modes for the 6
mosf popular industry standards for true “plug and play" capability.
For less common modes, its Digital Multiscan Technology will perform
all of fhe complex adjusfmenfs necessary to ensure a high quality picture
for any timing between 31 and 65 kHz.
NO. Resolution
(dots X lines)
Horizontal
Frequency Vertical
Frequency
I 640
X
330 31.5 kHz 70 Hz
2 640
X
400 31.5 kHz 70 Hz
3 640
X
480 31.5 kHz 60 Hz
4 640
X
480 37.5 kHz 75 Hz
5 800
X
600 46.9 kHz 75 Hz
6 1024x 768 60.0 kHz 75 Hz
Note for Windows® 95 users
If you cannot find this monitor (CPD-100VS) when you selected "SONY" on the device selector
display, select "DDC STANDARD MONITOR."
Windows'-' is a registered trademark of Microsoft Corporation in the United States and other
countries.
Note on recommended horizontal timing conditions
Horizontal sync width should be more than 1.0 psec.
Horizontal blanking width should be more than 3.6 psec.
■ To enter new timings
When using a videco mode that is not one of the 6 factory preset modes,
some fine tuning may be required to optimize the display to your
preferences. Simply adjust the monitor according to the adjustment
instructions. The adjustments will be stored automatically and recalled
whenever that mode is used.
A total of to user-defined modes can be stored in memory. If an 11th
mode is entered, it will replace the first.
