Identifying the Parts and Controls
Front Panel
[T]
POWER switch
FIVl/AM band selectors (See pages 9 and 10.)
Remote sensor
[
4
] Numeric buttons (See pages 9,10 and 11.)
[5] STANDBY indicator
(for U.K. and Australian models only)
The STANDBY indicator lights up when the power cord
is connected and the POWER switch is set to off.
[U VIDEO indicator
[7l
TV/LD indicator (See page 14.)
[si Display window
[H TUNING -f+ buttons (See pagelO.)
[T^ SUR (surround) ON/OFF button
(See pages 15,17 and 18.)
SUR (surround) MODE button
(See pages 15,17 and 18.)
CENTER MODE button
(See pages 15,16 and 17.)
DELAY TIME button (See page 18.)
|Ti]
SUR (surround) MODE indicators (See page 15.)
lil PRESET TUNING -/+ buttons (See page 11.)
m MEMORY button (See page 10.)
li^ MUTING button and indicator (See page 8.)
m MASTER VOLUME control (See page 8.)
Ill LOW BOOST button and indicator (See page 8.)
E7|
balance
control (See page 8.)
[il BASS/TREBLE controls (See page 8.)
[i^ SHIFT button (See pages 10 and 11.)
|2§ DIRECT button (See page 9.)
lU Function selectors (See page 8.)
1^ FM MODE button (See page 9.)
m HEADPHONES jack (See page 8.)
m SPEAKERS A/B buttons (See page 8.)
H REAR LEVEL -/+ buttons (See pages 17 and 18.)
H CENTER LEVEL -/+ buttons (See pages 17 and 18.)
