Sony STR-D515 - Manual (Page 22)

Specifications
(For U.K. and Australian models)
Amplifier section
Continuous RMS power output (8 ohms, at 40 Hz - 20 kHz less than
0.8% total harmoiuc distortion) (FRONT)
STR-D615: 60 W + 60 W
STR-D515: 50 W + 50 W
Dynamic power (at 1 kHz IHF) (FRONT)
STR-D615:80 W + 80 W (8 ohms), 110 W +110 W (4 ohms)
STR-D515: 70 W + 70 W (8 ohms), 100 W + 100 W (4 ohms)
Harmonic distortion
Less than 0.8% at rated output
SUR (surround) MODE (8 ohms, less than 0.8% total harmonic
distortion
Video section
STR-D615 STR-D515
FRONT 60 W +60 W 50W+50 W
CENTER (only in the
DOLBY surround mode)
50 W 20 W
REAR 20 W 20 W
Frequency response
PHONO: RIAA equalization curve ±0.5 dB
CD -1
VIDEO
10 Hz - 50 kHz ±1 dB
TAPE _
Inputs
Sensitivity Impedance S/N (weighting
network, input level)
PHONO 2.5 mV 50 kilohms 74 dB
72 dB* (A, 2.5 mV)
CD 300 mV 50 kilohms 95 dB
80 dB* (A, 200 mV)
VIDEO,
TV/LD
TAPE/MD 200 mV
»'78 IHF
Outputs
REC OUT, VIDEO
(AUDIO) OUT Voltage 200 mV
Impedance 10 kilohms
HEADPHONES Accepts low and high impedance
headphones
Tone controls
BASS; ±8 dB at 100 Hz
TREBLE; ±8 dB at 10 kHz
Muting
-20 dB
LOW BOOST
+10 dB at 70 Hz
INPUT VIDEO,
TV/LD 1 Vp-p 75 ohms
OUTPUT VIDEO
MONITOR 1 Vp-p 75 ohms
Tuner section
FM tuner section AM tuner section
Tuning range 87.5 —108 Ml-Iz 531 —1,602 kHz
Anteima
terminals
300 ohms, balanced
75 ohms, unbalanced External antenna
terminal
Sensitivity at
46 dB quieting 18.3 dBf, 4.5 pV (mono)
38.3 dBf, 45 pV (stereo) —
Usable
sensitivity
11.2 dBf,2pV (IHF) Loop antenna:
500 pV (at 999 kHz)
Signal-lo-noise
ratio 70 dB (mono)
66 dB (stereo) 54dB(at50mV/m)
Harmonic
distortion 0.3% (mono), 0.5%
(stereo) at 1 kHz 0.5%(at50mV/m,
400 Hz)
Selectivity 60 dB at 400 kHz 30 dB at 9 kHz
Separation 45 dB at 1 kHz —
Frequency
response 30 Hz —15 kHz
!fdB
—
General
System
Tuner section: PLL quartz-locked digital synthesizer
system
Preamplifier section: low-noise NF type equalizer amp
Power amplifier section: pure complementary SEPP
Power requirements
240 V AC, 50/60 Hz (for U.K. model)
240 V AC, 50 Hz (for Australian model)
Power consumption
165 W (STR-D615)
165 W (STR-D515)
In standby condition: 5 W
AC outlet
One switched (100 W Max.)
Dimensions
Approx. 430
X
135
X
295 mm (w/h/d)
(17 X 5 X 11 ^/j inches)
including projecting parts and controls
Mass
Approx. 6.9 kg (15 lb 4 oz) (STR-D615)
Approx. 6.4 kg (14 lb 2 oz) (STR-D515)
Accessories supplied
FM wire antenna (1)
AM loop antenna (1)
Remote Commander RM-P342 (1) (STR-D615)
Remote Commander RM-U242 (1) (STR-D515)
Sony batteries SUM-3(NS) (2)
Design and specifications are subject to change without notice.
22
Note
This appliance conforms with EEC Directive 87/308/EEC regarding
interference suppression.
