Specifications
Model KDL-26M3000/
KDL-26MLI30
KDL-32M3000/
KDL-32ML130
KDL-37M3000
System....................................
Television system NTSC: American TV standard
ATSC (
8 VSB terrestrial): ATSC compliant 8 VSB
QAM on cable: ANSI/SCTE 07 2(K)0 (Does not include CableCARD functionality)
Channel coverage Analog terrestrial; 2-69/ Digital terrestrial; 2-69
Analog Cable: I-125 / Digital Cable: 1-135
Panel system LCD (Liquid Ci 7 stal Display) Panel
Speaker output lo w-i- low
Input/Output jacks
.............................................................................................................................................................................................................................
Antenna 75-ohm external terminal for VHF/UHF
VIDEO IN I/2/3 S VIDEO (4~pin mini DIN)(VIDEO I only): Y: 1.0 Vp~p, 75 ohms unbalanced, sync negative /
C: 0.286 Vp-p (.Burst signal). 75 olims
VIDEO: 1 Vp-p. 75 ohms unbalanced, sync negative
AUDIO: 500 mVrms (100% modulation)/ Impedance; 47 kilohms
COMPONENT IN I/2 YP b PR (Component Video): Y: 1.0 Vp-p, 75 ohms unbalanced, sync negative / PB: 0.7 Vp-p. 75 olims /
PR: 0,7 Vp-p. 75 ohms / Signal format: 480i. 4B0p. 720p. lOBOi
AUDIO: 5(K) mVrms (100% modulalion)/ impedance: 47 kilohms
HDMI IN 1/2 HDMI: Video: 4B0i, 480p. 720p. lOBOi / Audio: Two channel linear PCM 32, 44,1 and 48 kHz. 16, 20 and 24bils
AUDIO: 500 mVrms (lOOSf modulation)/ Impedance: 47 kilohms
AUDIO OUT 500 mVmis (l(K)% modulation)/ More than 500 mVrms (Fixed)
PC IN D-sLih 15-pill, analog RGB, 0.7 Vp-p, 75 ohms, positive
See the PC Input Signal Reference Chart on page 18.
PC AUDIO INPUT Stereo mini jack. 500 mVrms. 47 kilohms
Headphones Stereo mini jack / Impedance; > 16 ohms
Power and others..............................................................................................................................................................................................................................
Power requirement ] 20 V AC. 60 Hz
Power consumption
in use 135 W now 180 W
in starulby All models less than 1 W
Sereen size (inches
rn ea s u re dd i ag
0 nal I y )
26 31.5 (32 class) 37
Display resolution
(horizontal
X vertical)
1.366 dots X 768 lines
Speaker/Full range (2) 146 X 35 mm
5 'V 4 X 1 ^/j= inches
Dimensions (W x H x D)
with stand (rnm)
(inches)
662 X 515 X 214
26 V^x 20 %x 8
796 X 590 X 214
31 X 23 V 4 X 8 ^/2
918x655 x265
36 V 4 X 25 X 10 V 2
without stand (inm)
(inches)
662 X 468 X 108
26 Vf^x IS V-2 x 4^/ j ^
796 X 544 X 100
31 Y^ x 2I V.yx4
918 X 509 X 108
36 V 4 X 24 X 4 -7^
wall-mount hole
pattern (mm) 200 X liXt 2(X> X 200 300 X 200
Mass
with stand 13 kg
29 lb,
16 kg
36 lb.
22 kg
49 lb.
w'ithout stand n kg
25 lb,
14 kg
31 lb.
18.5 kg
41 lb.
Supplied accessories Remote control RM-YD021 (1) / Size A A batteries (2) / Support bell (1) / Securing screw (1) / Wood screw (1) /
Cable holder (1 attached to the Table-Top Stand) / Operating Instructions (1) / Quick Setup Guide (1) / Warranty Card
(1) / Online Rcgi.stration Card (U.S.A. and Ctmada only) (1) / Wall-Mount: Installation Instructions (1)
Optional accessories Headphones plug adapter / Connecting cables I Wall-Mount Bracket: SU-WLIOO (KDL-26M3000 and KDL-26MLI30),
SU-WL500 (KDL-32M3000, KDL-32ML130, and KDL-37M3000) / 75-olim coaxial cable (1) / HD15-HD15 cable (1)
:»■
3"
S'
o'
3
’ Design and specifications are subject to change without notice.
