KBU64 Rackmount
User Manual
80-10100001-09
1–2
Fivemere
Fivemere
Figure 1.1 The KBU 64 Rackmount Version
Up to 13 KBU 64 card pairs may be fitted with either one or two power
supplies for resilience. The 1st card slot is for the Manager Card which
controls all cards within the rack via the KBU 64 polled management
system. If the Manager Card is not fitted, management of each card can
be performed by connecting a terminal directly to the command port of
the rear interface card. When fitted, the manager card must be placed in
slot 1, the left-hand most slot of the rack.
