KBU64 Rackmount
User Manual
80-10100001-09 iv
TABLE OF CONTENTS
1 KBU 64 RACKMOUNT SPECIFICATION 1–1
1.1 I NTRODUCTION 1–1
2 FRONT AND REAR PANELS AND INTERFACES 2–1
2.1 F RONT P ANEL 2–1
2.2 R EAR I NTERFACE C ARDS 2–1
2.2.1 L INK S ETTINGS 2–3
2.2.2 C OMMAND P ORT - KBU 64 R EAR I NTERFACE C ARDS 2–4
2.2.3 V35 R EAR I NTERFACE C ARD 2–5
2.2.4 X21 R EAR I NTERFACE C ARD 2–6
2.2.5 V24 R EAR I NTERFACE C ARD 2–6
3 MANAGER CARD 3–1
3.1 I NTRODUCTION 3–1
3.2 F RONT P ANEL 3–3
3.3 R EAR P ANEL 3–3
4 CARD INSTALLATION 4–1
4.1 M ANAGER C ARD I NSTALLATION 4–1
4.2 C ONFIGURATION U SING A M ANAGER C ARD 4–2
5 INSTALLATION AND POWER SUPPLY REQUIREMENTS 5–1
6 RACK SPECIFICATIONS 6–1
7 REGULATORY REQUIREMENTS 7–1
7.1 U NITED K INGDOM AND E UROPE 7–1
7.2 A DDITIONAL UK R EQUIREMENTS 7–1
