Manager Card
80-10100001-09 3–1
3 Manager Card
3.1 Introduction
The KBU 64 Manager Card is a discrete card for use with only
rackmount KBU 64 cards. Like the rackmount KBU 64, the Manager
Card also consists of a card pair. The rear card provides a command
port for management of all KBU 64 cards within its rack.
The Manager Card must always be fitted in slot 1, the slot on the left
when viewing the rack from the front.
Important
When the manager Card is used you cannot use the command port
of any KBU 64 Rear Interface Card. With the Manager Card fitted
you must remove links 12, 13 and 14 on every KBU 64 Rear
Interface Card to disconnect the card command interface. If you do
not do this the signal flow to the Manager Card will be corrupted.
