1 link settings – Cabletron Systems KBU64 Rackmount User Manual
Page 10
Front and Rear Panels and Interfaces
80-10100001-09
2–3
2.2.1 Link Settings
For all 3 types of Rear Interface Card the command port jumper settings
are as follows:
Without Manager Card
With
Manager
Card
Link
Normal
Polled
Polled Only
JP8
IN
IN
X
JP9
OUT
OUT
X
JP10
OUT
IN
X
JP11
IN
OUT
X
JP12
IN
IN
OUT
JP13
IN
IN
OUT
JP14
IN
IN
OUT
'X' = don't care
