Specifications
CPD-100ES/100EST
Picture tuLx’ 0.25 mm uperturc grille pitch
IS indies measured diagonall\'
90-degree deflection
Viewable image si/.e Approx. 285 x 214 mm (w/h)
(11 I /-t X 8 ' /2 inches)
14.0" viewing image
Logical resolution Horizontal; Max. 1280 dots
Vertical: Max. 1024 lines
Physical resolution Horizontal: Max. 1024 dots
Vertical: Max. 768 lines
Standard image area Approx. 270 x 202 mm (w/h)
(10
2 / 4
X 8 mche.s)
Deflection frequencv Horizontal: 30 to 70 kHz
Vertical: 50 to 120 Hz
AC input \'oltage/cLirrent
100 to 120 V, 50/60 Hz, 1-8 A
220 to 240 V, 50 - 60 Hz, 1 A
Dimensions Approx, 368 x 392 x 389 mm (w/h/d)
(14 '/2 X 15 1/2 X 15 2/8 inches)
Mass Approx. 14 kg (30 lb 14 oz)
CPD-200ES/200EST
Pin assignment
Video signal cable (HD15) (Male)
The cable accepts RGB x'ideo signals (0.714 Vp-p, positive)
and SYNC signals.
O I o
1
Pin No. Signal Pin No. Signal
1 Red 8 Blue Ground
2 Green
(Composite
Sync on Green)
9 —
10 Ground
11 Ground
3 Blue
12 Bi-Directional
Data (SDA)e
4 Ground
5 Ground 13 H.Sync
6 Red Ground 14 V. Sync
7 Green Ground 15 Data Clock (SCI.)«
* Display Data Channel (DDC) Standard by VESA.
Design and specifications are subject to change without
notice.
Picture tube 0.25 mm aperture grille pitch
17 inches measured diagonally
90-degree deflection
Viewable image size Approx. 327 x 243 mm (w/h)
(12 ''/gx 9 5/8 inches)
16.0" viewing image
Logical resolution Horizontal: Max. 1280 dots
Vertical: Max. 1024 lines
Physical resolution Horizontal: Max. 1280 dots
Vertical: Max. 1024 lines
Standard image area Approx. 312 x 234 mm (w/h)
(129/32x92/32 inches)
Deflection frequency Horizontal: 30 to 70 kHz
Vertical: 50 to 120 Hz
AC input voltage/current
100 to 240 V, 50/60 Hz, 1.8 A
220 to 240V, 50 - 60 Hz, 1 A
Dimensions Approx. 406 x 431.5 x 420 mm (w/h/d)
(16 X 17 X 16 5/8 inches)
Mass Approx. 18.5 kg (40 lb 13 oz)
