SLV-688/678HF
1/4 inch =1 inch Scale 4:1
DESCRIPTION: VHS HI-FI VCR POWER
DIMENSIONS
REQUIREMENTS:120V
(WHD):
14" X 4 1/8" X 11
POWER
60H
WEIG^
8 lbs. 2 oz.
CONSUMPTION: 25
Watts
FRONT VIEW
SIDE VIEW
3/4"
BACK VIEW
IT
L Audio R VIDEO
r\r UINI I
I34^
IN
VHF/UH^ ^^OU
NOTE:
WHERE THERE ARE CLOSE TOLERANCES INVOLVED IN CABINET BUILDING
OR APPLICATIONS WHICH REQUIRE A GREAT DEGREE OF PRECISION WE
RECOMMEND THAT THE PRODUCT ITSELF BE USED TO MAKE THE ACTUAL
MEASUREMENTS. SONY WILL NOT BE RESPONSIBLE FOR INACCURACIES
IN THE DESIGN OR MANUFACTURE OF ENCLOSURES .
Sony Electronics Inc • Consumer Integrated Systems • Park Ridge, New Jersey 07656
Features and specifications subject to change without notice. • Non-metric weights and measurements are approximate.
1/4
AC
IN
