Setting up the Player
LINE OUT
TO AUDIO I N / O U T
swItcM^h^io^r^od^
TO VIDEO I N / O U T
Audio / Video cable (supplied)
TV or monitor with
audio/video Inputs
LINE IN
switch to the “IN” mode
Audio / Video cable (supplied)
Camcorder or DVD Player
with audio / video outputs
NOTES:
• Refer to the owner’s manual of your TV as well.
• Before you connect the player to your TV be sure to turn off the power and unplug both units from
the wall outlet.
• Connect the player to your TV directly. If you connect the player to a VCR, the playback picture
will be distorted because DVD video discs are copy-protected.
• Be sure to slide the LINE SELECT IN/OUT switch to OUT, or the player may not work.
Switch between LiNE SELECT iN and LiNE SELECT OUT.
LINE SELECT IN: Receive an Input signal from an external source.
“ Line In ” appears on the LCD screen until a signal is received.
LINE SELECT OUT: Send a signal from the unit to the TV.
At this time, the player Is In normal playback mode.
44
