Connections
For Correct Connections
• Turn off the power of each unit before making
connections.
• Connect the AC power cord last.
• Be sure to insert the plugs firmly into the jacks.
Loose connection may cause hum and noise.
Leave a little slack in the connecting cord to allow for
inadvertent shock or vibration.
Cord plugs and jacks are color coded: Red plugs and
jacks are for the right channel (R) and white ones for the
left channel (L).
*iNotes on LINE OUT
FIXED: The output level is fixed.
VARIABLE: The output level can be adjusted with LINE
OUT/PHONE LEVEL control or LINE OUT
LEVEL buttons on the remote commander.
However, if the LINE OUT/PHONE LEVEL
control is turned while recording, the recording
level will change even when it is preset on the
tape deck.
*>Note on the CONTROL S IN 0nput)
To rennote control this unit through a CD player, receiver
or amplifier, connect the input on this unit to the
CONTROL S OUT (output) on a Sony CD player, receiver
or amplifier, with a CONTROL S cable.
*>Note on the CONTROL S OUT (output)
(CDP-C87ES only)
To renrrate control another CD player (supporting the Serial
Chain feature) through this unit, connect the output on this
unit to CONTROL S IN (input) on the other unit with a
(X>NTROLS cable.
Note on optical digital out
Connect the optical out to the amplifier with the optical
input or D/A converter. When you connect, use the
connecting cable for optical out POC-15 (not supplied).
When the optical out is connected, you cannot use fade
oirt, fade in, DSP mode etnd time fade function.
*«Note on the SERIAL CHAIN terminal and MODE
selector (CDP-C87ES only)
Use both serietl chain terminals to control two CD players
serially. See page 28 for details.
