Crimestopper Security Products CS-865RKE - Manual (Page 6)

CS-865RKE SEPARATE DRIVER’S DOOR UNLOCK DIAGRAMS
BLUE / WHITE
DRIVER'S
DOOR MOTOR
L
UL
(+) UNLOCK WIRE CUT
WHITE / BLACK
GREEN / BLACK
BLUE / BLACK
BROWN / BLACK
VIOLET / BLACK
86 85
87
30 87A
+
+12V
FUSED
+ L CUT
UL
CUT
MASTER
SWITCH
DRIVER PRIORITY UNLOCK with NEGATIVE TYPE DOOR LOCKS
BLUE / WHITE
DRIVER'S
DOOR MOTOR
L L
UL UL
FACTORY LOCK
RELAYS
(+) UNLOCK WIRE CUT
+12V
FUSED
WHITE / BLACK
GREEN / BLACK
BLUE / BLACK
BROWN / BLACK
VIOLET
+
NOT USED
DRIVER PRIORITY UNLOCK with REV. POLARITY DOOR LOCKS
VIOLET / BLACK
VIOLET
