010-ELV-121
| 7500-3080 |
Tech Support: 360-687-4530
[email protected]
TEMPERATURE SENSOR
KTM ThERMOSTAT REPLAcEMENT
08-14 KTM 200-300 Xc-W - 2 STROKE ONLy
11-14 hUSABERg TE250/300
KiT cONTENTS:
iNSTALLATiON:
1. Drain cooling system.
2. Remove OEM thermostat housing and radiator connecting hoses at bottom of thermostat.
3. Install coolant hose with one 3/4” hose clamp on head.
4. Install sensor body with two 3/4” hose clamps on coolant hose to frame and coolant hose to head.
5. Install new cross hose that connects the two radiators with existing hose clamps.
6. Refill cooling system.
7. Connect temperature sensor to computer.
8. Start engine and check for leaks before riding.
Sensor Body
coolant hose
3/4” hose clamp
