Replacement Parts
Order replacement parts from Taylor-Wharton Customer Service at 1-800-898-2657. Refer to the piping circuits section
on Page 8 to identify the components.
ITEM PART NUMBER DESCRIPTION
V-1 6914-4050 Globe Valve, 1/2” FNPT
V-2 2198262 Globe Valve, 3/8” FNPT
V-3 6914-4050 Globe Valve, 1/2” FNPT
V-4 2198262 Globe Valve, 3/8” FNPT
CV-1 6913-9365 Check Valve, Swing, ½” FNPT
CV-2 6913-9370 Check Valve, Ball-Cone, ½” FNPT
LI-1 57143700 Differential Pressure Gauge, 0-80 inches H2O
PI-1, 250 psi Vessel 7702-6196 Pressure Gauge, 400 psig
PI-1, 350/500 psi Vessel 7702-6197 Pressure Gauge, 600 psig
PCV-1, 250 psi Vessel 85368040 Regulator, Pressure Builder, 175 psig
PCV-1, 350 psi Vessel 85368042 Regulator, Pressure Builder, 300 psig
PCV-1, 500 psi Vessel 85368044 Regulator, Pressure Builder, 400 psig
PCV-2, 250 psi Vessel 85362615 Regulator, Economizer, 200 psig
PCV-2, 350 psi Vessel 1706-9C75 Regulator, Economizer, 325 psig
PCV-2, 500 psi Vessel 6999-9017 Regulator, Economizer, 425 psig
SV-1, 250 psi Vessel 85440299 Relief Valve, ½” MNPT, 250 psig
SV-1, 350 psi Vessel 85450298 Relief Valve, ½” MNPT, 350 psig
SV-1, 500 psi Vessel 85450299 Relief Valve, ½” MNPT, 500 psig
SV-2, 250/350 psi Vessel 6913-9072 Relief Valve, ¼” MNPT, 500 psig
SV-3, 250/350 psi Vessel 6913-9072 Relief Valve, ¼” MNPT, 500 psig
SV-2, 500 psi Vessel 6913-9079 Relief Valve, ¼” MNPT, 600 psig
SV-3, 500 psi Vessel 6913-9079 Relief Valve, ¼” MNPT, 600 psig
R-1, 250 psi Vessel M6009C33 Safety Disc, ½” MNPT, 356 psig
R-1, 350 psi Vessel 85163510 Safety Disc, ½” MNPT, 525 psig
R-1, 500 psi Vessel 85163520 Safety Disc, ½” MNPT, 750 psig
R-2 BC04-6C66 Casing Safety Disc
N/A 85449402 Diverter Valve (Optional)
N/A BCO4-9C87 Heater, 208/240 (Optional)
N/A BCO4-9C86 Heater Control (Optional)
N/A BC06-9C71 Well Assembly (Optional)
N/A H4509C10 Adaptor, Heater (Optional)
N/A H4509C20 Bracket, Heater Control (Optional)
N/A Q1KL9C36 Pallet, Steel (Optional)
