12-Strand Class II Tuck-Bury Eye Splice Modified for Saturn-12
S A M S O N S P L I C I N G I N S T R U C T I O N S
3
D
3
C
Attach a fid to the end of the
tapered tail and bury it from
the entry point through the
rope to exit beyond Mark 3.
Pull the tail until Marks 1 and 2
meet. Leave the tail exposed.
The 3 remaining strands are now routed from the entry point at Mark 2
to the exit point. Each strand is routed separately, entering at the entry
point and exiting at its own exit point. Do not pull the strands up tight
yet. Leave slack at the entry point.
With all 6 strands routed and the tail buried, pull each of the 6 routed
strands to remove any slack, and make sure the rope is smooth and
tight at the entry point.
z
z
s
s
z
s
z
z
s
s
z
s
mark 1
mark 2
mark 3
fid
mark 1
mark 2
mark 3
Burying the tail
routing last 3 strands
Pull out marked
strands and cut off
Mark 3 consecutive strands
3
E
At Mark 3, pull the tail out until Marks 1 and 2 meet. Pull any
slack out of the 6 strands that are routed. Pull out the tail and
mark 3 consecutive strands as shown. Pull out all 3 and cut off.
mark 1
mark 2
mark 3
mark 3
tapering tail
