TECHNICAL SPECIFICATION / MM INPUT
Generator source resistance = 40Ω.
Input sensitivity = 1.7mV for 200mV output.
Input loading = 47K in parallel with 100pF.
Maximum input level = 93mV at 1KHz.
Gain = 41.4dB at 1KHz.
Frequency response (100KΩ output load) = 15Hz (-3dB) to 100KHz (-0.2dB).
RIAA accuracy (100KΩ output load) = better than +/-0.2dB 100Hz to 100KHz.
THD+Noise = typically 0.005% at 1V Bandwidth 100Hz to 22KHz.
Noise (150Ω terminator on input) = typically –86dBV un-weighted 100Hz to 22KHz.
