LOG FILE PLAYBACK
16. Select [LOG] tab windows and then check the log from the log list using
mouse or click [Check All] button. Then click [Load] button.
GPS speed, G sensor X value, G sensor Y value, G sensor Z value data
can be used to narrow a search for journey information. The small check
box at right side of each value should be ticked before the data for search is
inputted. If any recorded video data matches the search query, a list will
show up with [Switch] or [G Sensor] indicators to show how the recording
was triggered.
LOG DATA will be recorded during driving even if there are no events. The
total log data size can not exceed (1,240MB). The unit overwrites the oldest
data when 48MB is reached. Using this log data, we can use the data sorting
function to help find specific data (for example, to find all the times when the
vehicle was travelling at more than 80mph(or 80km). Log data is stored in a
separate folder as a CSV file in GPS standard NMEA format.
Search button
Input sorting data
G-sensor graph
G sensor X value: Front/Back movement (like a harsh brake or quick start)
G sensor Y value: Left/Right movement (like a harsh turn)
G sensor Z value: Up/Down movement (like a bump or depression)
