NEVER LEAVE HEATER UNATTENDED WHILE BURNING,
CONNECTED TO A POWER SOURCE, OR WHILE
CONNECTED TO A FUEL SOURCE
© 2014, Pinnacle Products International, Inc. Propane Forced Air Heater User’s Manual
®
Item # Description PT-40-GFA PT-60V-GFA-A PT-125V-GFA-A PT-150V-GFA-A
1 Outer Shell 22-524-0020 22-524-0021 22-524-0022 22-524-0022
2 Inner Shell Assembly 22-524-0004 22-524-0004 22-524-0005 22-524-0005
3 Base 22-501-0003 22-501-0001 22-501-0002 22-501-0002
4 Height Controller 22-512-0005 22-512-0006 22-512-0008 22-512-0008
5 Base Cover 22-508-0003 22-508-0001 22-508-0002 22-508-0002
6 Inner Shell Cap 22-505-0006 22-505-0010 22-505-0011 22-505-0008
7 Multi Bracket Assembly 22-504-0002 22-504-0002 22-504-0003 22-504-0003
8 Thermal Switch 22-603-0001 22-603-0010 22-603-0001 22-603-0001
9 Tubing Assembly 22-605-0001 22-605-0001 22-605-0002 22-605-0003
10 Nozzle 22-081-0007 22-081-0014 22-081-0015 22-081-0004
11 Nozzle Nut 22-518-0001 22-518-0002 22-518-0002 22-518-0002
12 Handle 22-511-0004 22-511-0004 22-511-0004 22-511-0004
13 Flange Hex Nut 22-518-0003 22-518-0003 22-518-0003 22-518-0003
14 Fan 22-514-0001 22-514-0001 22-514-0002 22-514-0002
15 Cushion Pad 22-509-0001 22-509-0001 22-509-0001 22-509-0001
16 Motor Assembly 22-061-0015 22-061-0015 22-061-0016 22-061-0016
17 Guard 22-101-0003 22-101-0003 22-101-0004 22-101-0004
18 Round Bolt 22-503-0002 22-503-0002 22-503-0003 22-503-0003
19 Valve Assembly 22-011-0005 22-011-0017 22-011-0018 22-011-0008
20 Inlet Connector 22-507-0003 22-507-0003 22-507-0003 22-507-0003
21 Spark Module ‒ 22-604-0005 22-604-0005 22-604-0005
22 PCB Assembly 22-521-0001 22-521-0002 22-521-0002 22-521-0002
23 PCB Case 22-506-0001 22-506-0001 22-506-0001 22-506-0001
24 Valve Knob 22-516-0001 22-516-0001 22-516-0001 22-516-0001
25 Power Cord Assembly 22-131-0001 22-131-0001 22-131-0001 22-131-0001
26 Thermal Switch Cable 22-601-0001 22-601-0001 22-601-0001 22-601-0001
27 Hex Nut 22-518-0004 22-518-0004 22-518-0004 22-518-0004
28 Regulator Assembly 22-041-0004 22-041-0004 22-041-0005 22-041-0005
Parts List
12
