11-3 Removing The Main Unit
※
Keep the hook plate. You cannot remove the main unit without disengaging the hook plate.
(1) When the rear of the main unit has been secured with the method shown in the follow figure
unfasten the special screw.
(2) Remove the outer escutcheon.
(3) Insert the hook plate into the universal mounting bracket, then pull the main unit out by the hook
plate. (Insert both the right and left edges of the hook plate.)
Outer
escutcheon
2-Hook Plate
Unversal mounting bracket
Instrument panel
