QuickSpecs
Compaq Evo Desktop D300/300s
DA-10948 North America — Version 13 — May 9, 2002 8
Standard Features – Base Unit Details
Compaq Evo D es k top D3 00s Se ri es wi th 84 5 chip se t
Power Supply Full Ranging Input (No Line Select Switch) Yes
Active Power Factor Correction (APFC)
(Input Current is nearly ½ a non-APFC PS) Yes
Operating Voltage Range 90 to 264VAC
Rated Voltage Range 100 to 240VAC
Rated Line Frequency 50-60 Hz
Rated Input Current 3.6A @ 100VAC
Maximum Rated Power 250W
Heat Dissipation Max: 1,313 BTU/hr
Nominal: 656 BTU/hr
Max: 331 kg-cal/hr
Nominal: 165 kg-cal/hr
Power Conservation ‘Energy Saver’ Energy Star Compliant Yes
Blue Angel Compliant (<5w in S5-Power Off) Yes
Power Consumption in ES Mode -Suspend to RAM
(S3) (Instantly Available PC) TBD
APM Support Yes
Screen Blanking Yes
Hard Disk ‘Idle’ Mode Yes
System Idle Mode Yes
Processor/Cache Memory Power-Down (S3) Yes
CD-Rom Spins Down when not in use Yes
